6D4D

Crystal structure of the PTP epsilon D1 domain


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.76 Å
  • R-Value Free: 0.222
  • R-Value Work: 0.178
  • R-Value Observed: 0.180

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

High-resolution crystal structures of the D1 and D2 domains of protein tyrosine phosphatase epsilon for structure-based drug design.

Lountos, G.T.Raran-Kurussi, S.Zhao, B.M.Dyas, B.K.Burke Jr., T.R.Ulrich, R.G.Waugh, D.S.

(2018) Acta Crystallogr D Struct Biol 74: 1015-1026

  • DOI: 10.1107/S2059798318011919
  • Primary Citation of Related Structures:
    6D3F, 6D4D, 6D4F

  • PubMed Abstract:
  • Here, new crystal structures are presented of the isolated membrane-proximal D1 and distal D2 domains of protein tyrosine phosphatase epsilon (PTPℇ), a protein tyrosine phosphatase that has been shown to play a positive role in the survival of human breast cancer cells ...

    Here, new crystal structures are presented of the isolated membrane-proximal D1 and distal D2 domains of protein tyrosine phosphatase epsilon (PTPℇ), a protein tyrosine phosphatase that has been shown to play a positive role in the survival of human breast cancer cells. A triple mutant of the PTPℇ D2 domain (A455N/V457Y/E597D) was also constructed to reconstitute the residues of the PTPℇ D1 catalytic domain that are important for phosphatase activity, resulting in only a slight increase in the phosphatase activity compared with the native D2 protein. The structures reported here are of sufficient resolution for structure-based drug design, and a microarray-based assay for high-throughput screening to identify small-molecule inhibitors of the PTPℇ D1 domain is also described.


    Organizational Affiliation

    Macromolecular Crystallography Laboratory, Center for Cancer Research, National Cancer Institute, Frederick, MD 21702, USA.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Receptor-type tyrosine-protein phosphatase epsilonA, B292Homo sapiensMutation(s): 0
Gene Names: PTPRE
EC: 3.1.3.48
UniProt & NIH Common Fund Data Resources
Find proteins for P23469 (Homo sapiens)
Explore P23469
Go to UniProtKB:  P23469
PHAROS:  P23469
Protein Feature View
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.76 Å
  • R-Value Free: 0.222
  • R-Value Work: 0.178
  • R-Value Observed: 0.180
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 154.055α = 90
b = 35.998β = 115.73
c = 115.023γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-3000data reduction
HKL-3000data scaling
PHASERphasing

Structure Validation

View Full Validation Report




Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2018-10-17
    Type: Initial release
