6BP7

Recombinant major vault protein [Rattus norvegicus] structure in solution: conformation 2

  • Classification: STRUCTURAL PROTEIN
  • Organism(s): Rattus norvegicus
  • Expression System: Spodoptera frugiperda
  • Mutation(s): No

  • Deposited: 2017-11-22 Released: 2018-04-04
  • Deposition Author(s): Ding, K., Zhang, X., Mrazek, J., Kickhoefer, V.A., Lai, M., Ng, H.L., Yang, O.O., Rome, L.H., Zhou, Z.H.
  • Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS), National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID), National Institutes of Health/National Institute of Dental and Craniofacial Research (NIH/NIDCR), National Institutes of Health/National Center for Research Resources (NIH/NCRR), National Institutes of Health/Office of the Director, National Science Foundation (NSF, United States)

Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 4.90 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.4 of the entry. See complete history


Literature

Solution Structures of Engineered Vault Particles.

Ding, K.Zhang, X.Mrazek, J.Kickhoefer, V.A.Lai, M.Ng, H.L.Yang, O.O.Rome, L.H.Zhou, Z.H.

(2018) Structure 26: 619-626.e3

  • DOI: 10.1016/j.str.2018.02.014
  • Primary Citation of Related Structures:
    6BP7, 6BP8

  • PubMed Abstract:
  • Prior crystal structures of the vault have provided clues of its structural variability but are non-conclusive due to crystal packing. Here, we obtained vaults by engineering at the N terminus of rat major vault protein (MVP) an HIV-1 Gag protein segment and determined their near-atomic resolution (∼4 ...

    Prior crystal structures of the vault have provided clues of its structural variability but are non-conclusive due to crystal packing. Here, we obtained vaults by engineering at the N terminus of rat major vault protein (MVP) an HIV-1 Gag protein segment and determined their near-atomic resolution (∼4.8 Å) structures in a solution/non-crystalline environment. The barrel-shaped vaults in solution adopt two conformations, 1 and 2, both with D39 symmetry. From the N to C termini, each MVP monomer has three regions: body, shoulder, and cap. While conformation 1 is identical to one of the crystal structures, the shoulder in conformation 2 is translocated longitudinally up to 10 Å, resulting in an outward-projected cap. Our structures clarify the structural discrepancies in the body region in the prior crystallography models. The vault's drug-delivery potential is highlighted by the internal disposition and structural flexibility of its Gag-loaded N-terminal extension at the barrel waist of the engineered vault.


    Organizational Affiliation

    Department of Bioengineering, University of California, Los Angeles, Los Angeles, CA 90095, USA; California NanoSystems Institute, University of California, Los Angeles, Los Angeles, CA 90095, USA; Department of Microbiology, Immunology and Molecular Genetics, University of California, Los Angeles, Los Angeles, CA 90095, USA. Electronic address: hong.zhou@ucla.edu.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Major vault proteinA934Rattus norvegicusMutation(s): 0
Gene Names: Mvp
UniProt
Find proteins for Q62667 (Rattus norvegicus)
Explore Q62667
Go to UniProtKB:  Q62667
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ62667
Protein Feature View
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 4.90 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report




Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM071940
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United StatesAI094386
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United StatesAI043203
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United StatesAI106528
National Institutes of Health/National Institute of Dental and Craniofacial Research (NIH/NIDCR)United StatesDE025567
National Institutes of Health/National Center for Research Resources (NIH/NCRR)United States1S10RR23057
National Institutes of Health/Office of the DirectorUnited States1S10OD018111
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesU24GM116792
National Science Foundation (NSF, United States)United StatesDBI-338135

Revision History  (Full details and data files)

  • Version 1.0: 2018-04-04
    Type: Initial release
  • Version 1.1: 2018-04-11
    Changes: Data collection, Database references
  • Version 1.2: 2019-02-20
    Changes: Author supporting evidence, Data collection
  • Version 1.3: 2019-11-27
    Changes: Author supporting evidence
  • Version 1.4: 2019-12-18
    Changes: Other
