6BHY

Mouse Immunoglobulin G 2c Fc fragment with single GlcNAc


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.04 Å
  • R-Value Free: 0.254
  • R-Value Work: 0.210

wwPDB Validation 3D Report Full Report


This is version 1.0 of the entry. See complete history

Literature

Mouse IgG2c Fc loop residues promote greater receptor-binding affinity than mouse IgG2b or human IgG1.

Falconer, D.J.Barb, A.W.

(2018) PLoS ONE 13: e0192123-e0192123

  • DOI: 10.1371/journal.pone.0192123
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • The structures of non-human antibodies are largely unstudied despite the potential for the identification of alternative structural motifs and physical properties that will benefit a basic understanding of protein and immune system evolution as well ...

    The structures of non-human antibodies are largely unstudied despite the potential for the identification of alternative structural motifs and physical properties that will benefit a basic understanding of protein and immune system evolution as well as highlight unexplored motifs to improve therapeutic monoclonal antibody. Here we probe the structure and receptor-binding properties of the mouse IgG2c crystallizable fragment (Fc) to compare to mouse IgG2b and human IgG1 Fcs. Models of mIgG2c Fc determined by x-ray crystallography with a complex-type biantennary (to 2.05 Å) or a truncated (1)GlcNAc asparagine-linked (N)-glycan attached (to 2.04 Å) show differences in key regions related to mouse Fc γ receptor IV (mFcγRIV) binding. Mouse IgG2c forms different non-bonded interactions between the BC, DE and FG loops than the highly-conserved mIgG2b and binds to FcγRIV with 4.7-fold greater affinity in the complex-type glycoform. Secondary structural elements surrounding the Asn297 site of glycosylation form longer beta strands in the truncated mIgG2c Fc glycoform when compared to mIgG2c with the complex-type N-glycan. Solution NMR spectroscopy of the N-linked (1)GlcNAc residues show differences between mIgG2b, 2c and hIgG1 Fc that correlate to receptor binding affinity. Mutations targeting differences in mIgG2 DE and FG loops decreased affinity of mIgG2c for FcγRIV and increased affinity of mIgG2b. Changes in NMR spectra of the mutant Fc proteins mirrored these changes in affinity. Our studies identified structural and functional differences in highly conserved molecules that were not predicted from primary sequence comparison.


    Organizational Affiliation

    Roy J. Carver Department of Biochemistry, Biophysics and Molecular Biology Iowa State University, Ames, IA, United States of America.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Igh protein
A, B
238Mus musculusGene Names: Igh
Find proteins for Q58E56 (Mus musculus)
Go to UniProtKB:  Q58E56
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
NA
Query on NA

Download SDF File
Download CCD File
A, B
SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N
 Ligand Interaction
NAG
Query on NAG

Download SDF File
Download CCD File
A, B
N-ACETYL-D-GLUCOSAMINE
C8 H15 N O6
OVRNDRQMDRJTHS-FMDGEEDCSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.04 Å
  • R-Value Free: 0.254
  • R-Value Work: 0.210
  • Space Group: C 1 2 1
Unit Cell:
Length (Å)Angle (°)
a = 103.233α = 90.00
b = 89.215β = 132.20
c = 69.851γ = 90.00
Software Package:
Software NamePurpose
PHENIXphasing
PHENIXrefinement
JBluIce-EPICSdata collection
HKL-2000data scaling
HKL-2000data reduction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History & Funding Information

Deposition Data

  • Deposited Date: 2017-10-31
  • Released Date: 2018-02-14
  • Deposition Author(s): Falconer, D., Barb, A.

Funding OrganizationCountryGrant Number
National Institutes of Health/National Institute of General Medical SciencesUnited StatesGM115489

Revision History

  • Version 1.0: 2018-02-14
    Type: Initial release
