6BDN | pdb_00006bdn

Crystal structure of human TAO3 kinase binding ADP

• PDB DOI: https://doi.org/10.2210/pdb6BDN/pdb

• Classification: TRANSFERASE
• Organism(s): Homo sapiens
• Expression System: Spodoptera frugiperda
• Mutation(s): Yes


• Deposited: 2017-10-23 Released: 2019-04-10
• Deposition Author(s): Aleshin, A.E., Bankton, L.A., Pinkerton, A., Courtneidge, S.A., Liddington, R.C.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.50 Å
• R-Value Free:
  0.214 (Depositor), 0.220 (DCC)
• R-Value Work:
  0.186 (Depositor), 0.190 (DCC)
• R-Value Observed:
  0.187 (Depositor)

Starting Model: experimental

Literature

Crystal structure of human TAO3 kinase binding ADP

Aleshin, A.E., Bankton, L.A., Pinkerton, A., Liddington, R.C., Courtneidge, S.A.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 37.04 kDa
• Atom Count: 2,792
• Modeled Residue Count: 307
• Deposited Residue Count: 320
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Serine/threonine-protein kinase TAO3	A	320	Homo sapiens	Mutation(s): 2  Gene Names: TAOK3, DPK, JIK, KDS, MAP3K18 EC: 2.7.11.1
UniProt & NIH Common Fund Data Resources
Find proteins for Q9H2K8 (Homo sapiens) Explore Q9H2K8  Go to UniProtKB:  Q9H2K8
PHAROS:  Q9H2K8 GTEx:  ENSG00000135090

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
ADP (Subject of Investigation/LOI)	E [auth A]	ADENOSINE-5'-DIPHOSPHATE C10 H15 N5 O10 P2 XTWYTFMLZFPYCI-KQYNXXCUSA-N
SO4	C [auth A]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L
PO4	B [auth A]	PHOSPHATE ION O4 P NBIIXXVUZAFLBC-UHFFFAOYSA-K
MG (Subject of Investigation/LOI)	D [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.50 Å
• R-Value Free:  0.214 (Depositor), 0.220 (DCC)
• R-Value Work:  0.186 (Depositor), 0.190 (DCC)
• R-Value Observed: 0.187 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 55.187	α = 90
b = 59.897	β = 90
c = 110.177	γ = 90

Software Package:

Software Name	Purpose
Aimless	data scaling
REFMAC	refinement
PDB_EXTRACT	data extraction
XDS	data reduction
PHASER	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2019-04-10
Deposition Author(s): Aleshin, A.E., Bankton, L.A., Pinkerton, A., Courtneidge, S.A., Liddington, R.C.

Revision History

• Version 1.0: 2019-04-10
  Type: Initial release

• Version 1.1: 2023-10-04
  Changes: Data collection, Database references, Derived calculations, Refinement description
