6BB9 | pdb_00006bb9

The crystal structure of 4-amino-4-deoxychorismate lyase from Salmonella typhimurium LT2

PDB DOI: https://doi.org/10.2210/pdb6BB9/pdb

Classification: LYASE
Organism(s): Salmonella enterica subsp. enterica serovar Typhimurium
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2017-10-17 Released: 2017-10-25
Deposition Author(s): Tan, K., Makowska-Grzyska, M., Nocek, B., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)
Funding Organization(s): National Institutes of Health

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.28 Å
R-Value Free:
0.227 (Depositor), 0.232 (DCC)
R-Value Work:
0.190 (Depositor), 0.193 (DCC)
R-Value Observed:
0.191 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.2 of the entry. See complete history.

Literature

The crystal structure of 4-amino-4-deoxychorismate lyase from Salmonella typhimurium LT2

Tan, K., Makowska-Grzyska, M., Nocek, B., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 61.95 kDa
Atom Count: 4,355
Modeled Residue Count: 539
Deposited Residue Count: 544
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
4-amino-4-deoxychorismate lyase	A, B	272	Salmonella enterica subsp. enterica serovar Typhimurium	Mutation(s): 0 Gene Names: pabC, DD95_12385, STMU2UK_01164 EC: 4.1.3.38
UniProt
Find proteins for Q7CQR1 (Salmonella typhimurium (strain LT2 / SGSC1412 / ATCC 700720)) Explore Q7CQR1 Go to UniProtKB: Q7CQR1
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q7CQR1
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
MES Query on MES Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain D [auth A] SDF format, chain H [auth B] SDF format, chain I [auth B] MOL2 format, chain C [auth A] MOL2 format, chain D [auth A] MOL2 format, chain H [auth B] MOL2 format, chain I [auth B] mmCIF format, chain C [auth A] mmCIF format, chain D [auth A] mmCIF format, chain H [auth B] mmCIF format, chain I [auth B]	C [auth A], D [auth A], H [auth B], I [auth B]	2-(N-MORPHOLINO)-ETHANESULFONIC ACID C₆ H₁₃ N O₄ S SXGZJKUKBWWHRA-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth A] Focus chain H [auth B] Focus chain I [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth A] Focus chain H [auth B] Focus chain I [auth B]
SO4 Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain K [auth B] SDF format, chain L [auth B] MOL2 format, chain E [auth A] MOL2 format, chain K [auth B] MOL2 format, chain L [auth B] mmCIF format, chain E [auth A] mmCIF format, chain K [auth B] mmCIF format, chain L [auth B]	E [auth A], K [auth B], L [auth B]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain E [auth A] Focus chain K [auth B] Focus chain L [auth B] Interactions & Density Focus chain E [auth A] Focus chain K [auth B] Focus chain L [auth B]
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain J [auth B] MOL2 format, chain J [auth B] mmCIF format, chain J [auth B]	J [auth B]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain J [auth B] Interactions & Density Focus chain J [auth B]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain M [auth B] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain M [auth B] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain M [auth B]	F [auth A], G [auth A], M [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain F [auth A] Focus chain G [auth A] Focus chain M [auth B] Interactions & Density Focus chain F [auth A] Focus chain G [auth A] Focus chain M [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.28 Å
R-Value Free: 0.227 (Depositor), 0.232 (DCC)
R-Value Work: 0.190 (Depositor), 0.193 (DCC)
R-Value Observed: 0.191 (Depositor)

Space Group: P 6₁ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 87.25	α = 90
b = 87.25	β = 90
c = 308.949	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-3000	data reduction
HKL-3000	data scaling
HKL-3000	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2017-10-25

Deposition Author(s):

Center for Structural Genomics of Infectious Diseases (CSGID)

Funding Organization	Location	Grant Number
National Institutes of Health	United States	HHSN272201700060C

Revision History (Full details and data files)

Version 1.0: 2017-10-25
Type: Initial release
Version 1.1: 2017-12-06
Changes: Author supporting evidence
Version 1.2: 2023-10-04
Changes: Data collection, Database references, Refinement description
