6ARU | pdb_00006aru

Structure of Cetuximab Fab mutant in complex with EGFR extracellular domain

PDB DOI: https://doi.org/10.2210/pdb6ARU/pdb

Classification: TRANSFERASE/IMMUNE SYSTEM
Organism(s): Homo sapiens
Expression System: Homo sapiens
Mutation(s): No

Deposited: 2017-08-23 Released: 2018-08-29
Deposition Author(s): Christie, M., Christ, D.
Funding Organization(s): Australian Research Council (ARC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 3.20 Å
R-Value Free:
0.267 (Depositor), 0.260 (DCC)
R-Value Work:
0.232 (Depositor), 0.230 (DCC)
R-Value Observed:
0.234 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 2.2 of the entry. See complete history.

Literature

Structure of Cetuximab Fab mutant in complex with EGFR extracellular domain

Christie, M., Christ, D.

To be published.

Macromolecule Content

Total Structure Weight: 118.84 kDa
Atom Count: 8,087
Modeled Residue Count: 1,031
Deposited Residue Count: 1,058
Unique protein chains: 3

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Epidermal growth factor receptor	A	622	Homo sapiens	Mutation(s): 0 Gene Names: EGFR, ERBB, ERBB1, HER1 EC: 2.7.10.1
UniProt & NIH Common Fund Data Resources
Find proteins for P00533 (Homo sapiens) Explore P00533 Go to UniProtKB: P00533
PHAROS: P00533 GTEx: ENSG00000146648
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P00533
Glycosylation
Glycosylation Sites: 4	Glycosylation Focus chain A	Go to GlyGen: P00533-1
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Cetuximab mutant light chain,Uncharacterized protein	B	214	Homo sapiens	Mutation(s): 0
UniProt
Find proteins for Q8TCD0 (Homo sapiens) Explore Q8TCD0 Go to UniProtKB: Q8TCD0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q8TCD0
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Cetuximab mutant heavy chain Fab fragment,Immunoglobulin gamma-1 heavy chain	C	222	Homo sapiens	Mutation(s): 0
UniProt
Find proteins for P0DOX5 (Homo sapiens) Explore P0DOX5 Go to UniProtKB: P0DOX5
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P0DOX5
Glycosylation
Glycosylation Sites: 1	Glycosylation Focus chain C
Sequence Annotations Expand
Reference Sequence

Oligosaccharides

Help

Entity ID: 4
Molecule	Chains	Length	2D Diagram	Glycosylation	3D Interactions
alpha-D-mannopyranose-(1-3)-alpha-D-mannopyranose-(1-3)-[alpha-D-mannopyranose-(1-3)-[alpha-D-mannopyranose-(1-6)]alpha-D-mannopyranose-(1-6)]beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	D	8		N-Glycosylation	Interactions Focus chain D Interactions & Density Focus chain D
Glycosylation Resources
GlyTouCan: G96786JM GlyCosmos: G96786JM GlyGen: G96786JM

Entity ID: 5
Molecule	Chains	Length	2D Diagram	Glycosylation	3D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	E	2		N-Glycosylation	Interactions Focus chain E Interactions & Density Focus chain E
Glycosylation Resources
GlyTouCan: G42666HT GlyCosmos: G42666HT GlyGen: G42666HT

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAG Query on NAG Download Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain H [auth C] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth C] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth C]	F [auth A], G [auth A], H [auth C]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth C] Interactions & Density Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth C]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 3.20 Å
R-Value Free: 0.267 (Depositor), 0.260 (DCC)
R-Value Work: 0.232 (Depositor), 0.230 (DCC)
R-Value Observed: 0.234 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 77.495	α = 90
b = 70.444	β = 100.95
c = 149.079	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
Aimless	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History & Funding Information

Deposition Data

Released Date: 2018-08-29

Deposition Author(s):

Christie, M.

Christ, D.

Funding Organization	Location	Grant Number
Australian Research Council (ARC)	Australia	DE160100608
Australian Research Council (ARC)	Australia	DP160104915

Revision History (Full details and data files)

Version 1.0: 2018-08-29
Type: Initial release
Version 1.1: 2020-01-01
Changes: Author supporting evidence
Version 2.0: 2020-07-29
Type: Remediation
Reason: Carbohydrate remediation
Changes: Atomic model, Data collection, Derived calculations, Structure summary
Version 2.1: 2023-10-04
Changes: Data collection, Database references, Derived calculations, Refinement description, Structure summary
Version 2.2: 2024-11-20
Changes: Structure summary
