6ANA

LL2 Fab in complex with anti-Kappa VHH domain


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.70 Å
  • R-Value Free: 0.236
  • R-Value Work: 0.215
  • R-Value Observed: 0.215

wwPDB Validation 3D Report Full Report



Literature

Structural Basis of Enhanced Crystallizability Induced by a Molecular Chaperone for Antibody Antigen-Binding Fragments.

Ereno-Orbea, J.Sicard, T.Cui, H.Carson, J.Hermans, P.Julien, J.P.

(2018) J Mol Biol 430: 322-336

  • DOI: 10.1016/j.jmb.2017.12.010
  • Structures With Same Primary Citation

  • PubMed Abstract:
  • Monoclonal antibodies constitute one of the largest groups of drugs to treat cancers and immune disorders, and are guiding the design of vaccines against infectious diseases. Fragments antigen-binding (Fabs) have been preferred over monoclonal antibo ...

    Monoclonal antibodies constitute one of the largest groups of drugs to treat cancers and immune disorders, and are guiding the design of vaccines against infectious diseases. Fragments antigen-binding (Fabs) have been preferred over monoclonal antibodies for the structural characterization of antibody-antigen complexes due to their relatively low flexibility. Nonetheless, Fabs often remain challenging to crystallize because of the surface characteristics of complementary determining regions and the residual flexibility in the hinge region between the variable and constant domains. Here, we used a variable heavy-chain (V H H) domain specific for the human kappa light chain to assist in the structure determination of three therapeutic Fabs that were recalcitrant to crystallization on their own. We show that this ligand alters the surface properties of the antibody-ligand complex and lowers its aggregation temperature to favor crystallization. The V H H crystallization chaperone also restricts the flexible hinge of Fabs to a narrow range of angles, and so independently of the variable region. Our findings contribute a valuable approach to antibody structure determination and provide biophysical insight into the principles that govern the crystallization of macromolecules.


    Organizational Affiliation

    Program in Molecular Medicine, The Hospital for Sick Children Research Institute, Toronto, ON, Canada M5G 0A4; Department of Biochemistry, University of Toronto, Toronto, ON, Canada M5S 1A8; Department of Immunology, University of Toronto, Toronto, ON, Canada M5S 1A8. Electronic address: jean-philippe.julien@sickkids.ca.



Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
anti Kappa VHH domainK122Lama glamaMutation(s): 0
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
LL2 Fab Heavy ChainH219Mus musculusMutation(s): 0
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 3
MoleculeChainsSequence LengthOrganismDetails
LL2 Fab Light ChainL219Mus musculusMutation(s): 0
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence
Oligosaccharides
Entity ID: 4
MoleculeChainsChain Length2D Diagram Glycosylation
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-[alpha-L-fucopyranose-(1-6)]2-acetamido-2-deoxy-beta-D-glucopyranose
A
3 N-Glycosylation
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.70 Å
  • R-Value Free: 0.236
  • R-Value Work: 0.215
  • R-Value Observed: 0.215
  • Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 38.925α = 114.28
b = 63.682β = 96.14
c = 68.417γ = 91.92
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata scaling
PDB_EXTRACTdata extraction
XPREPdata reduction
PHENIXphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History

  • Version 1.0: 2018-01-31
    Type: Initial release
  • Version 1.1: 2018-02-14
    Changes: Database references
  • Version 1.2: 2019-10-16
    Changes: Advisory, Data collection, Structure summary
  • Version 2.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Atomic model, Data collection, Derived calculations, Structure summary
