5WAK | pdb_00005wak

Crystal Structure of a Suz12-Rbbp4 Binary Complex


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.20 Å
  • R-Value Free:
    0.251 (Depositor), 0.267 (DCC)
  • R-Value Work:
    0.178 (Depositor), 0.194 (DCC)
  • R-Value Observed:
    0.182 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5WAK

This is version 1.1 of the entry. See complete history

Literature

Unique Structural Platforms of Suz12 Dictate Distinct Classes of PRC2 for Chromatin Binding.

Chen, S.Jiao, L.Shubbar, M.Yang, X.Liu, X.

(2018) Mol Cell 69: 840-852.e5

  • DOI: https://doi.org/10.1016/j.molcel.2018.01.039
  • Primary Citation Related Structures:
    5WAI, 5WAK

  • PubMed Abstract:

    Developmentally regulated accessory subunits dictate PRC2 function. Here, we report the crystal structures of a 120 kDa heterotetrameric complex consisting of Suz12, Rbbp4, Jarid2, and Aebp2 fragments that is minimally active in nucleosome binding and of an inactive binary complex of Suz12 and Rbbp4. Suz12 contains two unique structural platforms that define distinct classes of PRC2 holo complexes for chromatin binding. Aebp2 and Phf19 compete for binding of a non-canonical C2 domain of Suz12; Jarid2 and EPOP occupy an overlapped Suz12 surface required for chromatin association of PRC2. Suz12 and Aebp2 progressively block histone H3K4 binding to Rbbp4, suggesting that Rbbp4 may not be directly involved in PRC2 inhibition by the active H3K4me3 histone mark. Nucleosome binding enabled by Jarid2 and Aebp2 is in part accounted for by the structures, which also reveal that disruption of the Jarid2-Suz12 interaction may underlie the disease mechanism of an oncogenic chromosomal translocation of Suz12.


  • Organizational Affiliation
    • Cecil H. and Ida Green Center for Reproductive Biology Sciences and Division of Basic Research, Department of Obstetrics and Gynecology, Department of Biophysics, UT Southwestern Medical Center, Dallas, TX 75390, USA.

Macromolecule Content

  • Total Structure Weight: 105.12 kDa
  • Atom Count: 4,766
  • Modeled Residue Count: 588
  • Deposited Residue Count: 917
  • Unique protein chains: 2

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Histone-binding protein RBBP4439Homo sapiensMutation(s): 0
Gene Names: RBBP4RBAP48
UniProt & NIH Common Fund Data Resources
Find proteins for Q09028 (Homo sapiens)
Explore Q09028
Go to UniProtKB:  Q09028
PHAROS:  Q09028
GTEx:  ENSG00000162521
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ09028
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Polycomb protein SUZ12478Homo sapiensMutation(s): 0
Gene Names: SUZ12CHET9JJAZ1KIAA0160
UniProt & NIH Common Fund Data Resources
Find proteins for Q15022 (Homo sapiens)
Explore Q15022
Go to UniProtKB:  Q15022
PHAROS:  Q15022
GTEx:  ENSG00000178691
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ15022
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ZN

Query on ZN



Download:Ideal Coordinates CCD File
C [auth B]ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.20 Å
  • R-Value Free:  0.251 (Depositor), 0.267 (DCC)
  • R-Value Work:  0.178 (Depositor), 0.194 (DCC)
  • R-Value Observed: 0.182 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 105.976α = 90
b = 107.696β = 90
c = 107.769γ = 90
Software Package:
Software NamePurpose
BUSTERrefinement
HKL-2000data reduction
HKL-2000data scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2018-03-14
    Type: Initial release
  • Version 1.1: 2023-10-04
    Changes: Data collection, Database references, Refinement description
