5T4Q

Autoinhibited E. coli ATP synthase state 3


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 8.53 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Cryo-EM structures of the autoinhibitedE. coliATP synthase in three rotational states.

Sobti, M.Smits, C.Wong, A.S.Ishmukhametov, R.Stock, D.Sandin, S.Stewart, A.G.

(2016) Elife 5: --

  • DOI: 10.7554/eLife.21598
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • A molecular model that provides a framework for interpreting the wealth of functional information obtained on the <i>E. coli </i> F-ATP synthase has been generated using cryo-electron microscopy. Three different states that relate to rotation of the ...

    A molecular model that provides a framework for interpreting the wealth of functional information obtained on the E. coli F-ATP synthase has been generated using cryo-electron microscopy. Three different states that relate to rotation of the enzyme were observed, with the central stalk's ε subunit in an extended autoinhibitory conformation in all three states. The F o motor comprises of seven transmembrane helices and a decameric c-ring and invaginations on either side of the membrane indicate the entry and exit channels for protons. The proton translocating subunit contains near parallel helices inclined by ~30° to the membrane, a feature now synonymous with rotary ATPases. For the first time in this rotary ATPase subtype, the peripheral stalk is resolved over its entire length of the complex, revealing the F 1 attachment points and a coiled-coil that bifurcates toward the membrane with its helices separating to embrace subunit a from two sides.


    Organizational Affiliation

    Department of Physics, Clarendon Laboratory, University of Oxford, Oxford, United Kingdom.,School of Biological Sciences, Nanyang Technological University, Singapore, Singapore.,Faculty of Medicine, The University of New South Wales, Sydney, Australia.,Molecular, Structural and Computational Biology Division, The Victor Chang Cardiac Research Institute, Darlinghurst, Australia.,NTU Institute of Structural Biology, Nanyang Technological University, Singapore, Singapore.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
ATP synthase subunit alpha
A, B, C
513Escherichia coli (strain K12)Mutation(s): 0
Gene Names: atpA (papA, uncA)
EC: 7.1.2.2
Membrane protein
mpstruct
Group:
TRANSMEMBRANE PROTEINS: ALPHA-HELICAL
Sub Group:
F-type ATPase
Protein:
Subunit C of the F1FO ATP synthase
Find proteins for P0ABB0 (Escherichia coli (strain K12))
Go to UniProtKB:  P0ABB0
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
ATP synthase subunit beta
D, E, F
471Escherichia coli (strain K12)Mutation(s): 0
Gene Names: atpD (papB, uncD)
EC: 7.1.2.2
Membrane protein
mpstruct
Group:
TRANSMEMBRANE PROTEINS: ALPHA-HELICAL
Sub Group:
F-type ATPase
Protein:
Subunit C of the F1FO ATP synthase
Find proteins for P0ABB4 (Escherichia coli (strain K12))
Go to UniProtKB:  P0ABB4
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetails
ATP synthase gamma chain
G
287Escherichia coli (strain K12)Mutation(s): 0
Gene Names: atpG (papC, uncG)
Membrane protein
mpstruct
Group:
TRANSMEMBRANE PROTEINS: ALPHA-HELICAL
Sub Group:
F-type ATPase
Protein:
Subunit C of the F1FO ATP synthase
Find proteins for P0ABA6 (Escherichia coli (strain K12))
Go to UniProtKB:  P0ABA6
Entity ID: 4
MoleculeChainsSequence LengthOrganismDetails
ATP synthase epsilon chain
H
139Escherichia coli (strain K12)Mutation(s): 0
Gene Names: atpC (papG, uncC)
Membrane protein
mpstruct
Group:
TRANSMEMBRANE PROTEINS: ALPHA-HELICAL
Sub Group:
F-type ATPase
Protein:
Subunit C of the F1FO ATP synthase
Find proteins for P0A6E6 (Escherichia coli (strain K12))
Go to UniProtKB:  P0A6E6
Entity ID: 5
MoleculeChainsSequence LengthOrganismDetails
ATP synthase subunit b
I, J
155Escherichia coli (strain K12)Mutation(s): 0
Gene Names: atpF (papF, uncF)
Membrane protein
mpstruct
Group:
TRANSMEMBRANE PROTEINS: ALPHA-HELICAL
Sub Group:
F-type ATPase
Protein:
Subunit C of the F1FO ATP synthase
Find proteins for P0ABA0 (Escherichia coli (strain K12))
Go to UniProtKB:  P0ABA0
Entity ID: 6
MoleculeChainsSequence LengthOrganismDetails
ATP synthase subunit a
K
271Escherichia coli (strain K12)Mutation(s): 0
Gene Names: atpB (papD, uncB)
Membrane protein
mpstruct
Group:
TRANSMEMBRANE PROTEINS: ALPHA-HELICAL
Sub Group:
F-type ATPase
Protein:
Subunit C of the F1FO ATP synthase
Find proteins for P0AB98 (Escherichia coli (strain K12))
Go to UniProtKB:  P0AB98
Entity ID: 7
MoleculeChainsSequence LengthOrganismDetails
ATP synthase subunit delta
L
177Escherichia coli (strain K12)Mutation(s): 0
Gene Names: atpH (papE, uncH)
Membrane protein
mpstruct
Group:
TRANSMEMBRANE PROTEINS: ALPHA-HELICAL
Sub Group:
F-type ATPase
Protein:
Subunit C of the F1FO ATP synthase
Find proteins for P0ABA4 (Escherichia coli (strain K12))
Go to UniProtKB:  P0ABA4
Entity ID: 8
MoleculeChainsSequence LengthOrganismDetails
ATP synthase subunit c
M, N, O, P, Q, R, S, T, U, V
79Escherichia coli (strain K12)Mutation(s): 0
Gene Names: atpE (papH, uncE)
Membrane protein
mpstruct
Group:
TRANSMEMBRANE PROTEINS: ALPHA-HELICAL
Sub Group:
F-type ATPase
Protein:
Subunit C of the F1FO ATP synthase
Find proteins for P68699 (Escherichia coli (strain K12))
Go to UniProtKB:  P68699
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ATP
Query on ATP

Download SDF File
Download CCD File
A, B, C
ADENOSINE-5'-TRIPHOSPHATE
C10 H16 N5 O13 P3
ZKHQWZAMYRWXGA-KQYNXXCUSA-N
 Ligand Interaction
ADP
Query on ADP

Download SDF File
Download CCD File
D
ADENOSINE-5'-DIPHOSPHATE
C10 H15 N5 O10 P2
XTWYTFMLZFPYCI-KQYNXXCUSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 8.53 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2017-01-04
    Type: Initial release
  • Version 1.1: 2018-03-28
    Type: Data collection, Database references
