5NEG | pdb_00005neg

ENAH EVH1 in complex with Ac-[2-Cl-F]-[ProM-2]-[ProM-13]-OEt


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.29 Å
  • R-Value Free:
    0.190 (Depositor), 0.190 (DCC)
  • R-Value Work:
    0.153 (Depositor), 0.153 (DCC)
  • R-Value Observed:
    0.155 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5NEG

Ligand Structure Quality Assessment


This is version 1.4 of the entry. See complete history

Literature

Designed nanomolar small-molecule inhibitors of Ena/VASP EVH1 interaction impair invasion and extravasation of breast cancer cells.

Barone, M.Muller, M.Chiha, S.Ren, J.Albat, D.Soicke, A.Dohmen, S.Klein, M.Bruns, J.van Dinther, M.Opitz, R.Lindemann, P.Beerbaum, M.Motzny, K.Roske, Y.Schmieder, P.Volkmer, R.Nazare, M.Heinemann, U.Oschkinat, H.Ten Dijke, P.Schmalz, H.G.Kuhne, R.

(2020) Proc Natl Acad Sci U S A 117: 29684-29690

  • DOI: https://doi.org/10.1073/pnas.2007213117
  • Primary Citation Related Structures:
    5N91, 5N9C, 5N9P, 5NAJ, 5NBF, 5NBX, 5NC2, 5NC7, 5NCF, 5NCG, 5NCP, 5ND0, 5NDU, 5NEG, 6RCF, 6RCJ, 6RD2, 6XVT, 6XXR, 7A5M, 7AKI

  • PubMed Abstract:

    Battling metastasis through inhibition of cell motility is considered a promising approach to support cancer therapies. In this context, Ena/VASP-depending signaling pathways, in particular interactions with their EVH1 domains, are promising targets for pharmaceutical intervention. However, protein-protein interactions involving proline-rich segments are notoriously difficult to address by small molecules. Hence, structure-based design efforts in combination with the chemical synthesis of additional molecular entities are required. Building on a previously developed nonpeptidic micromolar inhibitor, we determined 22 crystal structures of ENAH EVH1 in complex with inhibitors and rationally extended our library of conformationally defined proline-derived modules (ProMs) to succeed in developing a nanomolar inhibitor ([Formula: see text] Da). In contrast to the previous inhibitor, the optimized compounds reduced extravasation of invasive breast cancer cells in a zebrafish model. This study represents an example of successful, structure-guided development of low molecular weight inhibitors specifically and selectively addressing a proline-rich sequence-recognizing domain that is characterized by a shallow epitope lacking defined binding pockets. The evolved high-affinity inhibitor may now serve as a tool in validating the basic therapeutic concept, i.e., the suppression of cancer metastasis by inhibiting a crucial protein-protein interaction involved in actin filament processing and cell migration.


  • Organizational Affiliation
    • Department of Structural Biology, Leibniz-Forschungsinstitut für Molekulare Pharmakologie, 13125 Berlin, Germany.

Macromolecule Content

  • Total Structure Weight: 27.26 kDa
  • Atom Count: 2,241
  • Modeled Residue Count: 218
  • Deposited Residue Count: 226
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Protein enabled homolog
A, B
113Homo sapiensMutation(s): 0
Gene Names: ENAHMENA
UniProt & NIH Common Fund Data Resources
Find proteins for Q8N8S7 (Homo sapiens)
Explore Q8N8S7
Go to UniProtKB:  Q8N8S7
PHAROS:  Q8N8S7
GTEx:  ENSG00000154380
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8N8S7
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
8VK

Query on 8VK



Download:Ideal Coordinates CCD File
C [auth A],
H [auth B]
ethyl (3~{S},7~{R},10~{R},11~{R},13~{S})-4-[(3~{S},6~{R},8~{a}~{S})-1'-[(2~{S})-2-acetamido-3-(2-chlorophenyl)propanoyl]-5-oxidanylidene-spiro[1,2,3,8~{a}-tetrahydroindolizine-6,2'-pyrrolidine]-3-yl]carbonyl-11-ethyl-2-oxidanylidene-1,4-diazatricyclo[8.3.0.0^{3,7}]tridec-8-ene-13-carboxylate
C39 H48 Cl N5 O7
UDCSMDQSVHUJOU-FHKBVFMSSA-N
SO4

Query on SO4



Download:Ideal Coordinates CCD File
L [auth B]SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
NO3

Query on NO3



Download:Ideal Coordinates CCD File
D [auth A]
E [auth A]
F [auth A]
G [auth A]
I [auth B]
D [auth A],
E [auth A],
F [auth A],
G [auth A],
I [auth B],
J [auth B],
K [auth B]
NITRATE ION
N O3
NHNBFGGVMKEFGY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.29 Å
  • R-Value Free:  0.190 (Depositor), 0.190 (DCC)
  • R-Value Work:  0.153 (Depositor), 0.153 (DCC)
  • R-Value Observed: 0.155 (Depositor)
Space Group: P 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 34.81α = 90
b = 44.36β = 96.56
c = 72.47γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XSCALEdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2018-03-21
    Type: Initial release
  • Version 1.1: 2019-08-14
    Changes: Data collection
  • Version 1.2: 2020-11-25
    Changes: Database references
  • Version 1.3: 2022-10-26
    Changes: Database references
  • Version 1.4: 2024-01-31
    Changes: Data collection, Refinement description
