5NBX

ENAH EVH1 in complex with Ac-[2-Cl-F]-PP-[ProM-9]-OH


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.65 Å
  • R-Value Free: 0.195
  • R-Value Work: 0.167
  • R-Value Observed: 0.168

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

Designed nanomolar small-molecule inhibitors of Ena/VASP EVH1 interaction impair invasion and extravasation of breast cancer cells

Barone, M.Roske, Y.

(2020) Proc Natl Acad Sci U S A


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Protein enabled homologA, B113Homo sapiensMutation(s): 0
Gene Names: ENAHMENA
UniProt & NIH Common Fund Data Resources
Find proteins for Q8N8S7 (Homo sapiens)
Explore Q8N8S7
Go to UniProtKB:  Q8N8S7
PHAROS:  Q8N8S7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8N8S7
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 5 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
8SN
Query on 8SN

Download Ideal Coordinates CCD File
H [auth A],
M [auth B]
(3~{S},7~{R},10~{R},11~{R},13~{S})-11-methyl-2-oxidanylidene-1,4-diazatricyclo[8.3.0.0^{3,7}]tridec-8-ene-13-carboxylic acid
C13 H18 N2 O3
PMVIXGKHVFHPBB-NMUGVGKYSA-N
 Ligand Interaction
2L5
Query on 2L5

Download Ideal Coordinates CCD File
D [auth A],
I [auth B]
2-chloro-L-phenylalanine
C9 H10 Cl N O2
CVZZNRXMDCOHBG-QMMMGPOBSA-N
 Ligand Interaction
PRO
Query on PRO

Download Ideal Coordinates CCD File
E [auth A],
F [auth A],
J [auth B],
K [auth B]
PROLINE
C5 H9 N O2
ONIBWKKTOPOVIA-BYPYZUCNSA-N
 Ligand Interaction
BR
Query on BR

Download Ideal Coordinates CCD File
C [auth A]BROMIDE ION
Br
CPELXLSAUQHCOX-UHFFFAOYSA-M
 Ligand Interaction
ACY
Query on ACY

Download Ideal Coordinates CCD File
G [auth A],
L [auth B]
ACETIC ACID
C2 H4 O2
QTBSBXVTEAMEQO-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.65 Å
  • R-Value Free: 0.195
  • R-Value Work: 0.167
  • R-Value Observed: 0.168
  • Space Group: C 2 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 90.214α = 90
b = 131.615β = 90
c = 35.704γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XSCALEdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2018-03-21
    Type: Initial release
  • Version 1.1: 2020-11-25
    Changes: Database references, Derived calculations
