5N8Q

Structure of truncated Norcoclaurine Synthase from Thalictrum flavum


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.236
  • R-Value Work: 0.197
  • R-Value Observed: 0.199

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Structural Evidence for the Dopamine-First Mechanism of Norcoclaurine Synthase.

Lichman, B.R.Sula, A.Pesnot, T.Hailes, H.C.Ward, J.M.Keep, N.H.

(2017) Biochemistry 56: 5274-5277

  • DOI: https://doi.org/10.1021/acs.biochem.7b00769
  • Primary Citation of Related Structures:
    5N8Q, 5NON

  • PubMed Abstract:

    Norcoclaurine synthase (NCS) is a Pictet-Spenglerase that catalyzes the first key step in plant benzylisoquinoline alkaloid metabolism, a compound family that includes bioactive natural products such as morphine. The enzyme has also shown great potential as a biocatalyst for the formation of chiral isoquinolines. Here we present new high-resolution X-ray crystallography data describing Thalictrum flavum NCS bound to a mechanism-inspired ligand. The structure supports two key features of the NCS "dopamine-first" mechanism: the binding of dopamine catechol to Lys-122 and the position of the carbonyl substrate binding site at the active site entrance. The catalytically vital residue Glu-110 occupies a previously unobserved ligand-bound conformation that may be catalytically significant. The potential roles of inhibitory binding and alternative amino acid conformations in the mechanism have also been revealed. This work significantly advances our understanding of the NCS mechanism and will aid future efforts to engineer the substrate scope and catalytic properties of this useful biocatalyst.


  • Organizational Affiliation

    Department of Biochemical Engineering, University College London , Gower Street, London WC1E 6BT, U.K.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
S-norcoclaurine synthase
A, B, C
165Thalictrum flavum subsp. glaucumMutation(s): 0
EC: 4.2.1.78
UniProt
Find proteins for Q67A25 (Thalictrum flavum subsp. glaucum)
Explore Q67A25
Go to UniProtKB:  Q67A25
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ67A25
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.236
  • R-Value Work: 0.197
  • R-Value Observed: 0.199
  • Space Group: P 2 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 38.046α = 90
b = 109.632β = 90
c = 136.739γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
DIALSdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Wellcome TrustUnited Kingdom096626/Z/11/Z

Revision History  (Full details and data files)

  • Version 1.0: 2017-09-27
    Type: Initial release
  • Version 1.1: 2017-10-18
    Changes: Database references
  • Version 1.2: 2024-01-17
    Changes: Data collection, Database references, Refinement description
