5LJT

Crystal structure of human carbonic anhydrase II in complex with the 4-((1-phenyl-1H-1,2,3-triazol-4-yl)methoxy)benzenesulfonamide inhibitor


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.00 Å
  • R-Value Free: 0.157
  • R-Value Work: 0.138
  • R-Value Observed: 0.139

wwPDB Validation 3D Report Full Report



Literature

Benzenesulfonamides Incorporating Flexible Triazole Moieties Are Highly Effective Carbonic Anhydrase Inhibitors: Synthesis and Kinetic, Crystallographic, Computational, and Intraocular Pressure Lowering Investigations.

Nocentini, A.Ferraroni, M.Carta, F.Ceruso, M.Gratteri, P.Lanzi, C.Masini, E.Supuran, C.T.

(2016) J Med Chem 59: 10692-10704

  • DOI: 10.1021/acs.jmedchem.6b01389
  • Structures With Same Primary Citation

  • PubMed Abstract:
  • Herein we report the synthesis of two series of benzenesulfonamide containing compounds that incorporate the phenyl-1,2,3-triazole moieties. We explored the insertion of appropriate linkers, such as ether, thioether, and amino type, into the inner se ...

    Herein we report the synthesis of two series of benzenesulfonamide containing compounds that incorporate the phenyl-1,2,3-triazole moieties. We explored the insertion of appropriate linkers, such as ether, thioether, and amino type, into the inner section of the molecules with the intent to confer additional flexibility. All obtained compounds were screened in vitro as inhibitors of the physiologically relevant human (h) isoforms of the metalloenzyme carbonic anhydrase (CA, EC 4.2.1.1). Many of them were low nanomolar or subnanomolar hCA II, IX, and XII inhibitors, whereas they did not potently inhibit hCA I. Computational and X-ray crystallographic studies of the enzyme-inhibitor adducts helped us to rationalize the obtained results. Some of the sulfonamides reported here showed significant intraocular pressure lowering activity in an animal model of glaucoma.


    Organizational Affiliation

    Università degli Studi di Firenze , Neurofarba Department., Sezione di Scienze Farmaceutiche, Via Ugo Schiff 6, 50019 Sesto Fiorentino (Florence), Italy.



Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Carbonic anhydrase 2
A
258Homo sapiensMutation(s): 0
Gene Names: CA2
EC: 4.2.1.1
Find proteins for P00918 (Homo sapiens)
Go to UniProtKB:  P00918
NIH Common Fund Data Resources
PHAROS  P00918
Protein Feature View
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
A6N
Query on A6N

Download CCD File
A
4-[[4-[azanyl-bis(oxidanyl)-$l^{4}-sulfanyl]phenoxy]methyl]-1-phenyl-1,2,3-triazole
C15 H16 N4 O3 S
CAKKFQLFMKZHOH-UHFFFAOYSA-N
 Ligand Interaction
GOL
Query on GOL

Download CCD File
A
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
 Ligand Interaction
ZN
Query on ZN

Download CCD File
A
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
 Ligand Interaction
External Ligand Annotations
IDBinding Affinity (Sequence Identity %)
A6NKi:  1.2000000476837158   nM  Binding MOAD
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.00 Å
  • R-Value Free: 0.157
  • R-Value Work: 0.138
  • R-Value Observed: 0.139
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 42.363α = 90
b = 41.4β = 104.41
c = 72.171γ = 90
Software Package:
Software NamePurpose
XSCALEdata scaling
REFMACrefinement
PDB_EXTRACTdata extraction
XDSdata reduction
REFMACphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History

  • Version 1.0: 2017-06-21
    Type: Initial release
