5L3I | pdb_00005l3i

Re-refinement of 4dd6; cisplatin coordination chemistry determination at hen egg white lysozyme His15

PDB DOI: https://doi.org/10.2210/pdb5L3I/pdb
Entry: 5L3I supersedes: 4DD6

Classification: HYDROLASE
Organism(s): Gallus gallus
Mutation(s): No

Deposited: 2016-05-06 Released: 2016-06-15
Deposition Author(s): Helliwell, J.R.
Funding Organization(s): Engineering and Physical Sciences Research Council

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free:
0.212 (Depositor), 0.219 (DCC)
R-Value Work:
0.181 (Depositor), 0.183 (DCC)
R-Value Observed:
0.182 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 2.1 of the entry. See complete history.

Literature

Cisplatin coordination chemistry determination at hen egg white lysozyme His15 with ligand distances and angles, and their standard uncertainties, and also reporting a split occupancy effect

Helliwell, J.R., Schreurs, A.M.M., Kroon-Batenburg, L.M.J., Tanley, S.

(2016) ArXiv

DOI: https://doi.org/10.3927/45371856

Macromolecule Content

Total Structure Weight: 15.83 kDa
Atom Count: 1,152
Modeled Residue Count: 129
Deposited Residue Count: 129
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Lysozyme C	A	129	Gallus gallus	Mutation(s): 0 EC: 3.2.1.17
UniProt
Find proteins for P00698 (Gallus gallus) Explore P00698 Go to UniProtKB: P00698
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P00698
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 5 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
PT Query on PT Download:Ideal Coordinates CCD File SDF format, chain S [auth A] SDF format, chain Q [auth A] SDF format, chain P [auth A] SDF format, chain E [auth A] SDF format, chain D [auth A] MOL2 format, chain S [auth A] MOL2 format, chain Q [auth A] MOL2 format, chain P [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] mmCIF format, chain S [auth A] mmCIF format, chain Q [auth A] mmCIF format, chain P [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A]	D [auth A], E [auth A], P [auth A], Q [auth A], S [auth A]	PLATINUM (II) ION Pt HRGDZIGMBDGFTC-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain E [auth A] Focus chain P [auth A] Focus chain Q [auth A] Focus chain S [auth A] Interactions & Density Focus chain D [auth A] Focus chain E [auth A] Focus chain P [auth A] Focus chain Q [auth A] Focus chain S [auth A]
DMS Query on DMS Download:Ideal Coordinates CCD File SDF format, chain O [auth A] SDF format, chain N [auth A] SDF format, chain B [auth A] MOL2 format, chain O [auth A] MOL2 format, chain N [auth A] MOL2 format, chain B [auth A] mmCIF format, chain O [auth A] mmCIF format, chain N [auth A] mmCIF format, chain B [auth A]	B [auth A], N [auth A], O [auth A]	DIMETHYL SULFOXIDE C₂ H₆ O S IAZDPXIOMUYVGZ-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Focus chain N [auth A] Focus chain O [auth A] Interactions & Density Focus chain B [auth A] Focus chain N [auth A] Focus chain O [auth A]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain R [auth A] SDF format, chain M [auth A] SDF format, chain L [auth A] SDF format, chain K [auth A] SDF format, chain J [auth A] SDF format, chain F [auth A] MOL2 format, chain R [auth A] MOL2 format, chain M [auth A] MOL2 format, chain L [auth A] MOL2 format, chain K [auth A] MOL2 format, chain J [auth A] MOL2 format, chain F [auth A] mmCIF format, chain R [auth A] mmCIF format, chain M [auth A] mmCIF format, chain L [auth A] mmCIF format, chain K [auth A] mmCIF format, chain J [auth A] mmCIF format, chain F [auth A]	F [auth A] J [auth A] K [auth A] L [auth A] M [auth A] F [auth A], J [auth A], K [auth A], L [auth A], M [auth A], R [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain F [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain R [auth A] Interactions & Density Focus chain F [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain R [auth A]
NA Query on NA Download:Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	SODIUM ION Na FKNQFGJONOIPTF-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]
NH3 Query on NH3 Download:Ideal Coordinates CCD File SDF format, chain I [auth A] SDF format, chain H [auth A] SDF format, chain G [auth A] MOL2 format, chain I [auth A] MOL2 format, chain H [auth A] MOL2 format, chain G [auth A] mmCIF format, chain I [auth A] mmCIF format, chain H [auth A] mmCIF format, chain G [auth A]	G [auth A], H [auth A], I [auth A]	AMMONIA H₃ N QGZKDVFQNNGYKY-UHFFFAOYSA-N		Interactions Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Interactions & Density Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free: 0.212 (Depositor), 0.219 (DCC)
R-Value Work: 0.181 (Depositor), 0.183 (DCC)
R-Value Observed: 0.182 (Depositor)

Diffraction Data:

Space Group: P 4₃ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 78.016	α = 90
b = 78.016	β = 90
c = 37.071	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2016-06-15

Deposition Author(s):

Helliwell, J.R.

This entry supersedes: 4DD6

Funding Organization	Location	Grant Number
Engineering and Physical Sciences Research Council	United Kingdom	--

Revision History (Full details and data files)

Version 1.0: 2016-06-15
Type: Initial release
Version 1.1: 2016-09-28
Changes: Database references
Version 1.2: 2017-09-13
Changes: Author supporting evidence
Version 2.0: 2024-01-10
Changes: Atomic model, Data collection, Database references, Derived calculations, Refinement description
Version 2.1: 2024-11-13
Changes: Structure summary
