Crystal structure of LiuC in complex with coenzyme A and malonic acid

Experimental Data Snapshot

  • Resolution: 1.10 Å
  • R-Value Free: 0.145
  • R-Value Work: 0.125
  • R-Value Observed: 0.126

wwPDB Validation   3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.2 of the entry. See complete history


The Structure of LiuC, a 3-Hydroxy-3-Methylglutaconyl CoA Dehydratase Involved in Isovaleryl-CoA Biosynthesis in Myxococcus xanthus, Reveals Insights into Specificity and Catalysis.

Bock, T.Reichelt, J.Muller, R.Blankenfeldt, W.

(2016) Chembiochem 17: 1658-1664

  • DOI: https://doi.org/10.1002/cbic.201600225
  • Primary Citation of Related Structures:
    5JBW, 5JBX

  • PubMed Abstract:

    Myxobacteria are able to produce the important metabolite isovaleryl coenzyme A by a route other than leucine degradation. The first step into this pathway is mediated by LiuC, a member of the 3-methylglutaconyl CoA hydratases (MGCH). Here we present crystal structures refined to 2.05 and 1.1 Å of LiuC in the apo form and bound to coenzyme A, respectively. By using simulated annealing we modeled the enzyme substrate complex and identified residues potentially involved in substrate binding, specificity, and catalysis. The dehydration of 3-hydroxy-3-methylglutaconyl CoA to 3-methylglutaconyl CoA catalyzed by LiuC involves Glu112 and Glu132 and likely employs the typical crotonase acid-base mechanism. In this, Tyr231 and Arg69 are key players in positioning the substrate to enable catalysis. Surprisingly, LiuC shows higher sequence and structural similarity to human MGCH than to bacterial forms, although they convert the same substrate. This study provides structural insights into the alternative isovaleryl coenzyme A biosynthesis pathway and might open a path for biofuel research, as isovaleryl-CoA is a source for isobutene, a precursor for renewable fuels and chemicals.

  • Organizational Affiliation

    Structure and Function of Proteins, Helmholtz Centre for Infection Research, Inhoffenstrasse 7, 38124, Braunschweig, Germany.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
3-hydroxybutyryl-CoA dehydratase
A, B, C
261Myxococcus xanthus DK 1622Mutation(s): 0
Gene Names: crtMXAN_3757
Find proteins for Q1D5Y4 (Myxococcus xanthus (strain DK1622))
Explore Q1D5Y4
Go to UniProtKB:  Q1D5Y4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ1D5Y4
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 1.10 Å
  • R-Value Free: 0.145
  • R-Value Work: 0.125
  • R-Value Observed: 0.126
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 74.834α = 90
b = 84.773β = 90
c = 128.634γ = 90
Software Package:
Software NamePurpose
Aimlessdata scaling
PDB_EXTRACTdata extraction
XDSdata reduction

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2016-06-22
    Type: Initial release
  • Version 1.1: 2016-09-14
    Changes: Database references
  • Version 1.2: 2024-01-10
    Changes: Data collection, Database references, Refinement description
