5ZOH

Crystal structure of a far-red light-absorbing form of AnPixJg2_BV4 in complex with biliverdin


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.60 Å
  • R-Value Free: 0.241
  • R-Value Work: 0.206
  • R-Value Observed: 0.208

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

Rational conversion of chromophore selectivity of cyanobacteriochromes to accept mammalian intrinsic biliverdin.

Fushimi, K.Miyazaki, T.Kuwasaki, Y.Nakajima, T.Yamamoto, T.Suzuki, K.Ueda, Y.Miyake, K.Takeda, Y.Choi, J.H.Kawagishi, H.Park, E.Y.Ikeuchi, M.Sato, M.Narikawa, R.

(2019) Proc Natl Acad Sci U S A 116: 8301-8309

  • DOI: 10.1073/pnas.1818836116
  • Primary Citation of Related Structures:
    5ZOH

  • PubMed Abstract:
  • Because cyanobacteriochrome photoreceptors need only a single compact domain for chromophore incorporation and for absorption of visible spectra including the long-wavelength far-red region, these molecules have been paid much attention for application to bioimaging and optogenetics ...

    Because cyanobacteriochrome photoreceptors need only a single compact domain for chromophore incorporation and for absorption of visible spectra including the long-wavelength far-red region, these molecules have been paid much attention for application to bioimaging and optogenetics. Most cyanobacteriochromes, however, have a drawback to incorporate phycocyanobilin that is not available in the mammalian cells. In this study, we focused on biliverdin (BV) that is a mammalian intrinsic chromophore and absorbs the far-red region and revealed that replacement of only four residues was enough for conversion from BV-rejective cyanobacteriochromes into BV-acceptable molecules. We succeeded in determining the crystal structure of one of such engineered molecules, AnPixJg2_BV4, at 1.6 Å resolution. This structure identified unusual covalent bond linkage, which resulted in deep BV insertion into the protein pocket. The four mutated residues contributed to reducing steric hindrances derived from the deeper insertion. We introduced these residues into other domains, and one of them, NpF2164g5_BV4, produced bright near-infrared fluorescence from mammalian liver in vivo. Collectively, this study provides not only molecular basis to incorporate BV by the cyanobacteriochromes but also rational strategy to open the door for application of cyanobacteriochromes to visualization and regulation of deep mammalian tissues.


    Organizational Affiliation

    Research Institute of Green Science and Technology, Shizuoka University, 422-8529 Shizuoka, Japan.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Methyl-accepting chemotaxis proteinA197Nostoc sp. PCC 7120 = FACHB-418Mutation(s): 4
Gene Names: all1069
UniProt
Find proteins for Q8YXY7 (Nostoc sp. (strain PCC 7120 / SAG 25.82 / UTEX 2576))
Explore Q8YXY7
Go to UniProtKB:  Q8YXY7
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
BLA (Subject of Investigation/LOI)
Query on BLA

Download Ideal Coordinates CCD File
B [auth A]BILIVERDINE IX ALPHA
C33 H34 N4 O6
GWZYPXHJIZCRAJ-SRVCBVSDSA-N
 Ligand Interaction
GOL
Query on GOL

Download Ideal Coordinates CCD File
C [auth A]GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.60 Å
  • R-Value Free: 0.241
  • R-Value Work: 0.206
  • R-Value Observed: 0.208
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 65.957α = 90
b = 60.65β = 108.59
c = 55.475γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
HKL-2000data reduction
HKL-2000data scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Japan Science and TechnologyJapan--

Revision History  (Full details and data files)

  • Version 1.0: 2019-04-17
    Type: Initial release
  • Version 1.1: 2019-05-08
    Changes: Data collection, Database references
