5Z5N | pdb_00005z5n

Crystal structure of ConA-R1M

• PDB DOI: https://doi.org/10.2210/pdb5Z5N/pdb

• Classification: SUGAR BINDING PROTEIN
• Organism(s): Canavalia ensiformis
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2018-01-18 Released: 2018-11-07
• Deposition Author(s): Chen, G.S., Gan, J.H., Hu, R.T.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.04 Å
• R-Value Free:
  0.225 (Depositor), 0.230 (DCC)
• R-Value Work:
  0.169 (Depositor), 0.180 (DCC)
• R-Value Observed:
  0.172 (Depositor)

Literature

Crystal structure of ConA-R1M (Only Mannose)

Chen, G.S., Gan, J.H., Hu, R.T.

To be published.

Biological Assembly 1

Global Symmetry: Dihedral - D2  (Explore in 3D)
Global Stoichiometry: Homo 4-mer - A4

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: homology

Macromolecule Content

• Total Structure Weight: 103.05 kDa
• Atom Count: 7,514
• Modeled Residue Count: 924
• Deposited Residue Count: 948
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Concanavalin-A	A, B, C, D	237	Canavalia ensiformis	Mutation(s): 0
UniProt
Find proteins for P02866 (Canavalia ensiformis) Explore P02866  Go to UniProtKB:  P02866

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
MAN	I [auth B]	alpha-D-mannopyranose C6 H12 O6 WQZGKKKJIJFFOK-PQMKYFCFSA-N
MN	F [auth A], H [auth B], K [auth C], M [auth D]	MANGANESE (II) ION Mn WAEMQWOKJMHJLA-UHFFFAOYSA-N
CA	E [auth A], G [auth B], J [auth C], L [auth D]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.04 Å
• R-Value Free:  0.225 (Depositor), 0.230 (DCC)
• R-Value Work:  0.169 (Depositor), 0.180 (DCC)
• R-Value Observed: 0.172 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 66.21	α = 90
b = 118.82	β = 90
c = 120.45	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-2000	data reduction
HKL-2000	data scaling
PHASER	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2018-11-07
Deposition Author(s): Chen, G.S., Gan, J.H., Hu, R.T.

Revision History

• Version 1.0: 2018-11-07
  Type: Initial release

• Version 1.1: 2020-07-29
  Type: Remediation
  Reason: Carbohydrate remediation
  Changes: Data collection, Derived calculations, Structure summary
• Version 1.2: 2024-03-27
  Changes: Data collection, Database references, Structure summary
