Structure of house dust mite allergen Der F 21 in PEG2KMME

Experimental Data Snapshot

  • Resolution: 2.30 Å
  • R-Value Free: 0.273
  • R-Value Work: 0.221
  • R-Value Observed: 0.223

wwPDB Validation   3D Report Full Report

This is version 1.2 of the entry. See complete history


Crystal structure and epitope analysis of house dust mite allergen Der f 21.

Pang, S.L.Ho, K.L.Waterman, J.Rambo, R.P.Teh, A.H.Mathavan, I.Harris, G.Beis, K.Say, Y.H.Anusha, M.S.Sio, Y.Y.Chew, F.T.Ng, C.L.

(2019) Sci Rep 9: 4933-4933

  • DOI: https://doi.org/10.1038/s41598-019-40879-x
  • Primary Citation of Related Structures:
    5YNX, 5YNY

  • PubMed Abstract:

    Group 21 and 5 allergens are homologous house dust mite proteins known as mid-tier allergens. To reveal the biological function of group 21 allergens and to understand better the allergenicity of the rDer f 21 allergen, we determined the 1.5 Å crystal structure of rDer f 21 allergen from Dermatophagoides farinae. The rDer f 21 protein consists of a three helical bundle, similar to available structures of group 21 and homologous group 5 allergens. The rDer f 21 dimer forms a hydrophobic binding pocket similar to the one in the Der p 5 allergen, which indicates that both of the homologous groups could share a similar function. By performing structure-guided mutagenesis, we mutated all 38 surface-exposed polar residues of the rDer f 21 allergen and carried out immuno-dot blot assays using 24 atopic sera. Six residues, K10, K26, K42, E43, K46, and K48, which are located in the region between the N-terminus and the loop 1 of rDer f 21 were identified as the major IgE epitopes of rDer f 21. Epitope mapping of all potential IgE epitopes on the surface of the rDer f 21 crystal structure revealed heterogeneity in the sIgE recognition of the allergen epitopes in atopic individuals. The higher the allergen-sIgE level of an individual, the higher the number of epitope residues that are found in the allergen. The results illustrate the clear correlation between the number of specific major epitope residues in an allergen and the sIgE level of the atopic population.

  • Organizational Affiliation

    Institute of Systems Biology, Universiti Kebangsaan Malaysia, 43600 UKM Bangi, Selangor, Malaysia.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Allergen Der f 21
A, B, C, D
128Dermatophagoides farinaeMutation(s): 0
Find proteins for B2GM84 (Dermatophagoides farinae)
Explore B2GM84
Go to UniProtKB:  B2GM84
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB2GM84
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 2.30 Å
  • R-Value Free: 0.273
  • R-Value Work: 0.221
  • R-Value Observed: 0.223
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 63.237α = 90
b = 50.934β = 97.33
c = 69.642γ = 90
Software Package:
Software NamePurpose
PDB_EXTRACTdata extraction
XDSdata reduction
XSCALEdata scaling
Cootmodel building

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
Other governmentMalaysiaGUP-2014- 010

Revision History  (Full details and data files)

  • Version 1.0: 2019-03-13
    Type: Initial release
  • Version 1.1: 2019-09-25
    Changes: Data collection, Database references
  • Version 1.2: 2024-03-27
    Changes: Data collection, Database references, Refinement description
