5YEJ

Crystal structure of BioQ with its naturel double-stranded DNA operator


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.698 Å
  • R-Value Free: 0.265
  • R-Value Work: 0.212

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Structural insights into operator recognition by BioQ in the Mycobacterium smegmatis biotin synthesis pathway.

Yan, L.Tang, Q.Guan, Z.Pei, K.Zou, T.He, J.

(2018) Biochim Biophys Acta Gen Subj 1862: 1843-1851


Macromolecules

Find similar proteins by: Sequence  |  Structure


Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
TetR family transcriptional regulator
A, B, C
232N/AMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.
Entity ID: 2
MoleculeChainsLengthOrganism
DNA (5'-D(*AP*CP*CP*TP*GP*AP*AP*CP*AP*CP*CP*GP*TP*TP*CP*AP*AP*GP*T)-3')D,G19synthetic construct
Entity ID: 3
MoleculeChainsLengthOrganism
DNA (5'-D(*AP*CP*TP*TP*GP*AP*AP*CP*GP*GP*TP*GP*TP*TP*CP*AP*GP*GP*T)-3')F19synthetic construct
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.698 Å
  • R-Value Free: 0.265
  • R-Value Work: 0.212
  • Space Group: C 1 2 1
Unit Cell:
Length (Å)Angle (°)
a = 60.687α = 90.00
b = 212.468β = 99.43
c = 88.126γ = 90.00
Software Package:
Software NamePurpose
CRANK2phasing
PHENIXrefinement
Aimlessdata scaling
XDSdata reduction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2018-09-26
    Type: Initial release
  • Version 1.1: 2018-10-03
    Type: Data collection, Database references
  • Version 1.2: 2018-10-10
    Type: Data collection, Derived calculations, Structure summary
