5YB4

Crystal structure of HP23LN36KR


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.5 Å
  • R-Value Free: 0.267
  • R-Value Work: 0.188

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Structural Insights into the Mechanisms of Action of Short-Peptide HIV-1 Fusion Inhibitors Targeting the Gp41 Pocket

Zhang, X.Zhu, Y.Hu, H.Zhang, S.Wang, P.Chong, H.He, J.Wang, X.He, Y.

(2018) Front Cell Infect Microbiol 8: 51-51

  • DOI: 10.3389/fcimb.2018.00051
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • The deep hydrophobic pocket of HIV-1 gp41 has been considered a drug target, but short-peptides targeting this site usually lack potent antiviral activity. By applying the M-T hook structure, we previously generated highly potent short-peptide fusion ...

    The deep hydrophobic pocket of HIV-1 gp41 has been considered a drug target, but short-peptides targeting this site usually lack potent antiviral activity. By applying the M-T hook structure, we previously generated highly potent short-peptide fusion inhibitors that specifically targeted the pocket site, such as MT-SC22EK, HP23L, and LP-11. Here, the crystal structures of HP23L and LP-11 bound to the target mimic peptide N36 demonstrated the critical intrahelical and interhelical interactions, especially verifying that the hook-like conformation was finely adopted while the methionine residue was replaced by the oxidation-less prone residue leucine, and that addition of an extra glutamic acid significantly enhanced the binding and inhibitory activities. The structure of HP23L bound to N36 with two mutations (E49K and L57R) revealed the critical residues and motifs mediating drug resistance and provided new insights into the mechanism of action of inhibitors. Therefore, the present data help our understanding for the structure-activity relationship (SAR) of HIV-1 fusion inhibitors and facilitate the development of novel antiviral drugs.


    Organizational Affiliation

    Institute of Pathogen Biology and Center for AIDS Research, Chinese Academy of Medical Sciences and Peking Union Medical College, Beijing, China.,College of Life Sciences and Bioengineering, School of Science, Beijing Jiaotong University, Beijing, China.,Ministry of Education Key Laboratory of Protein Science, Beijing Advanced Innovation Center for Structural Biology, School of Life Sciences, Tsinghua University, Beijing, China.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
N36KR
E, D, F
36Human immunodeficiency virus type 1 group M subtype B (isolate HXB2)Mutation(s): 0
Gene Names: env
Find proteins for P04578 (Human immunodeficiency virus type 1 group M subtype B (isolate HXB2))
Go to UniProtKB:  P04578
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
HP23L
H, G, I
23N/AMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.5 Å
  • R-Value Free: 0.267
  • R-Value Work: 0.188
  • Space Group: P 41 21 2
Unit Cell:
Length (Å)Angle (°)
a = 51.280α = 90.00
b = 51.280β = 90.00
c = 142.950γ = 90.00
Software Package:
Software NamePurpose
PHASERphasing
PHENIXrefinement
HKL-2000data scaling
HKL-2000data reduction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2018-02-28
    Type: Initial release
  • Version 1.1: 2018-03-28
    Type: Database references
