5YAW | pdb_00005yaw

Fragment-based Drug Discovery of inhibitors to block PDEdelta-RAS protein-protein interaction

PDB DOI: https://doi.org/10.2210/pdb5YAW/pdb

Classification: ONCOPROTEIN
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2017-09-01 Released: 2018-09-05
Deposition Author(s): Bing, X., Yanlian, L., Danyan, C.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.03 Å
R-Value Free:
0.252 (Depositor), 0.250 (DCC)
R-Value Work:
0.216 (Depositor), 0.220 (DCC)
R-Value Observed:
0.218 (Depositor)

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Fragment-based Drug Discovery of inhibitors to block PDEdelta-RAS protein-protein interaction

Bing, X., Yanlian, L., Danyan, C.

To be published.

Macromolecule Content

Total Structure Weight: 17.81 kDa
Atom Count: 1,343
Modeled Residue Count: 146
Deposited Residue Count: 150
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Retinal rod rhodopsin-sensitive cGMP 3',5'-cyclic phosphodiesterase subunit delta	A [auth B]	150	Homo sapiens	Mutation(s): 0 Gene Names: PDE6D, PDED
UniProt & NIH Common Fund Data Resources
Find proteins for O43924 (Homo sapiens) Explore O43924 Go to UniProtKB: O43924
PHAROS: O43924 GTEx: ENSG00000156973
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	O43924
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
8SL Query on 8SL Download Ideal Coordinates CCD File SDF format, chain B MOL2 format, chain B mmCIF format, chain B	B	3-[(4-methoxyphenyl)methylsulfanyl]-5-(2-methylpropyl)-4-(phenylmethyl)-1,2,4-triazole C₂₁ H₂₅ N₃ O S WYMPXNJKMFASMX-UHFFFAOYSA-N		Interactions Focus chain B Interactions & Density Focus chain B

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.03 Å
R-Value Free: 0.252 (Depositor), 0.250 (DCC)
R-Value Work: 0.216 (Depositor), 0.220 (DCC)
R-Value Observed: 0.218 (Depositor)

Space Group: P 3₂ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 56.148	α = 90
b = 56.148	β = 90
c = 116.161	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data processing
XDS	data scaling
PHENIX	model building

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Released Date: 2018-09-05

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2018-09-05
Type: Initial release
Version 1.1: 2024-03-27
Changes: Data collection, Database references
