5Y4L

PRRSV nsp4


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.252
  • R-Value Work: 0.213
  • R-Value Observed: 0.214

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Identification of two antiviral inhibitors targeting 3C-like serine/3C-like protease of porcine reproductive and respiratory syndrome virus and porcine epidemic diarrhea virus.

Shi, Y.Lei, Y.Ye, G.Sun, L.Fang, L.Xiao, S.Fu, Z.F.Yin, P.Song, Y.Peng, G.

(2018) Vet Microbiol 213: 114-122

  • DOI: https://doi.org/10.1016/j.vetmic.2017.11.031
  • Primary Citation of Related Structures:
    5Y4L

  • PubMed Abstract:

    Porcine reproductive and respiratory syndrome virus (PRRSV) and porcine epidemic diarrhea virus (PEDV) are highly virulent and contagious porcine pathogens that cause tremendous economic losses to the swine industry worldwide. Currently, there is no effective treatment for PRRSV and PEDV, and commercial vaccines do not induce sterilizing immunity. In this study, we screened a library of 1000 compounds and identified two specific inhibitors, designated compounds 2 and 3, which target the PRRSV 3C-like serine protease (3CLSP). First, we evaluated the inhibitory effects of compounds 2 and 3 on PRRSV 3CLSP activity. Next, we determined the anti-PRRSV capacity of compounds 2 and 3 in MARC-145 cells and obtained EC 50 and CC 50 values of 57μM (CC 50 =479.9μM) and 56.8μM (CC 50 =482.8μM), respectively. Importantly, compounds 2 and 3 also targeted the PEDV 3C-like protease (3CL protease) and inhibited PEDV replication, showing EC 50 and CC 50 values of 100μM (CC 50 =533.8μM) and 57.9μM (CC 50 =522.3μM), respectively. Finally, our results indicated that the active sites (His39 in 3CLSP and His41 in 3CL protease) were conservative, and contacted compounds 2 and 3 via hydrogen bonds and hydrophobic forces in the putative substrate-binding models. In summary, compounds 2 and 3 exhibit broad-spectrum antiviral activity and may facilitate the development of antiviral drugs against PRRSV and PEDV.


  • Organizational Affiliation

    State Key Laboratory of Agricultural Microbiology, Huazhong Agricultural University, Wuhan 430070, China; College of Veterinary Medicine, Huazhong Agricultural University, Wuhan 430070, China; The Cooperative Innovation Center for Sustainable Pig Production, Huazhong Agricultural University, Wuhan 430070, China; College of Life Science and Technology, Huazhong Agricultural University, Wuhan 430070, China.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Non-structural proteinA [auth B],
B [auth A],
C,
D
214Porcine reproductive and respiratory syndrome virusMutation(s): 0
Gene Names: ORF1a
UniProt
Find proteins for A1E8J1 (Porcine reproductive and respiratory syndrome virus)
Explore A1E8J1
Go to UniProtKB:  A1E8J1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA1E8J1
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.252
  • R-Value Work: 0.213
  • R-Value Observed: 0.214
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 76.681α = 90
b = 86.117β = 90
c = 142.955γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data collection
HKL-2000data scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
China--

Revision History  (Full details and data files)

  • Version 1.0: 2018-01-17
    Type: Initial release
  • Version 1.1: 2019-01-30
    Changes: Data collection, Database references
  • Version 1.2: 2024-03-27
    Changes: Data collection, Database references
