5Y1W | pdb_00005y1w

Crystal structure of Plasmodium falciparum aminopeptidase N with Magnesium bound to active site Zinc

• PDB DOI: https://doi.org/10.2210/pdb5Y1W/pdb

• Classification: HYDROLASE
• Organism(s): Plasmodium falciparum FcB1/Columbia
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2017-07-21 Released: 2018-08-01
• Deposition Author(s): Marapaka, A.K., Addlagatta, A.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.56 Å
• R-Value Free:
  0.206 (Depositor), 0.215 (DCC)
• R-Value Work:
  0.170 (Depositor), 0.184 (DCC)
• R-Value Observed:
  0.172 (Depositor)

Starting Model: experimental

Literature

Crystal structure of Plasmodium falciparum aminopeptidase N with Magnesium bound to active site Zinc

Marapaka, A.K., Addlagatta, A.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 106.52 kDa
• Atom Count: 8,085
• Modeled Residue Count: 890
• Deposited Residue Count: 914
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
M1 family aminopeptidase	A	914	Plasmodium falciparum FcB1/Columbia	Mutation(s): 0  EC: 3.4.11
UniProt
Find proteins for O96935 (Plasmodium falciparum (isolate 3D7)) Explore O96935  Go to UniProtKB:  O96935

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
GOL	F [auth A]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N
ZN	B [auth A]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N
MG	C [auth A], D [auth A], E [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.56 Å
• R-Value Free:  0.206 (Depositor), 0.215 (DCC)
• R-Value Work:  0.170 (Depositor), 0.184 (DCC)
• R-Value Observed: 0.172 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 74.421	α = 90
b = 109.205	β = 90
c = 112.477	γ = 90

Software Package:

Software Name	Purpose
DENZO	data collection
SCALEPACK	data scaling
MOLREP	model building
REFMAC	refinement
PDB_EXTRACT	data extraction
DENZO	data reduction

Structure Validation

Entry History

Deposition Data

• Released Date: 2018-08-01
Deposition Author(s): Marapaka, A.K., Addlagatta, A.

Revision History

• Version 1.0: 2018-08-01
  Type: Initial release

• Version 1.1: 2023-11-22
  Changes: Data collection, Database references, Derived calculations, Refinement description
