5XUU

Crystal structure of Lachnospiraceae bacterium ND2006 Cpf1 in complex with crRNA and target DNA (TCCA PAM)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free: 0.244
  • R-Value Work: 0.193
  • R-Value Observed: 0.195

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Structural Basis for the Canonical and Non-canonical PAM Recognition by CRISPR-Cpf1.

Yamano, T.Zetsche, B.Ishitani, R.Zhang, F.Nishimasu, H.Nureki, O.

(2017) Mol Cell 67: 633-645.e3

  • DOI: 10.1016/j.molcel.2017.06.035
  • Primary Citation of Related Structures:
    5XUZ, 5XUS, 5XUU, 5XUT

  • PubMed Abstract:
  • The RNA-guided Cpf1 (also known as Cas12a) nuclease associates with a CRISPR RNA (crRNA) and cleaves the double-stranded DNA target complementary to the crRNA guide. The two Cpf1 orthologs from Acidaminococcus sp. (AsCpf1) and Lachnospiraceae bacterium (LbCpf1) have been harnessed for eukaryotic genome editing ...

    The RNA-guided Cpf1 (also known as Cas12a) nuclease associates with a CRISPR RNA (crRNA) and cleaves the double-stranded DNA target complementary to the crRNA guide. The two Cpf1 orthologs from Acidaminococcus sp. (AsCpf1) and Lachnospiraceae bacterium (LbCpf1) have been harnessed for eukaryotic genome editing. Cpf1 requires a specific nucleotide sequence, called a protospacer adjacent motif (PAM), for target recognition. Besides the canonical TTTV PAM, Cpf1 recognizes suboptimal C-containing PAMs. Here, we report four crystal structures of LbCpf1 in complex with the crRNA and its target DNA containing either TTTA, TCTA, TCCA, or CCCA as the PAM. These structures revealed that, depending on the PAM sequences, LbCpf1 undergoes conformational changes to form altered interactions with the PAM-containing DNA duplexes, thereby achieving the relaxed PAM recognition. Collectively, the present structures advance our mechanistic understanding of the PAM-dependent, crRNA-guided DNA cleavage by the Cpf1 family nucleases.


    Organizational Affiliation

    Department of Biological Sciences, Graduate School of Science, The University of Tokyo, 2-11-16 Yayoi, Bunkyo-ku, Tokyo 113-0032, Japan. Electronic address: nureki@bs.s.u-tokyo.ac.jp.



Macromolecules

Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
LbCpf1A1231Lachnospiraceae bacterium ND2006Mutation(s): 0
Find proteins for A0A182DWE3 (Lachnospiraceae bacterium ND2006)
Explore A0A182DWE3
Go to UniProtKB:  A0A182DWE3
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence
Find similar nucleic acids by:
(by identity cutoff)  |  Structure
Entity ID: 3
MoleculeChainsLengthOrganismImage
DNA (29-MER)C29synthetic construct
  • Find similar nucleic acids by:  Sequence   |   Structure
  • Entity ID: 4
    MoleculeChainsLengthOrganismImage
    DNA (5'-D(*CP*GP*TP*CP*CP*TP*CP*CP*A)-3')D9synthetic construct
    Find similar nucleic acids by:
    (by identity cutoff)  |  Structure
    Entity ID: 2
    MoleculeChainsLengthOrganismImage
    crRNAB40synthetic construct
    Small Molecules
    Ligands 3 Unique
    IDChainsName / Formula / InChI Key2D Diagram3D Interactions
    EDO
    Query on EDO

    Download CCD File
    A
    1,2-ETHANEDIOL
    C2 H6 O2
    LYCAIKOWRPUZTN-UHFFFAOYSA-N
     Ligand Interaction
    MG
    Query on MG

    Download CCD File
    A
    MAGNESIUM ION
    Mg
    JLVVSXFLKOJNIY-UHFFFAOYSA-N
     Ligand Interaction
    NA
    Query on NA

    Download CCD File
    B
    SODIUM ION
    Na
    FKNQFGJONOIPTF-UHFFFAOYSA-N
     Ligand Interaction
    Experimental Data & Validation

    Experimental Data

    • Method: X-RAY DIFFRACTION
    • Resolution: 2.50 Å
    • R-Value Free: 0.244
    • R-Value Work: 0.193
    • R-Value Observed: 0.195
    • Space Group: P 41 21 2
    Unit Cell:
    Length ( Å )Angle ( ˚ )
    a = 101.954α = 90
    b = 101.954β = 90
    c = 372.544γ = 90
    Software Package:
    Software NamePurpose
    PHENIXrefinement
    DIALSdata reduction
    Aimlessdata scaling
    MOLREPphasing

    Structure Validation

    View Full Validation Report



    Entry History

    Deposition Data

    Revision History

    • Version 1.0: 2017-08-09
      Type: Initial release
    • Version 1.1: 2017-12-06
      Changes: Database references
