Crystal structure of the F61S mutant of HsNUDT16

  • Classification: HYDROLASE
  • Organism(s): Homo sapiens
  • Expression System: Escherichia coli
  • Mutation(s): Yes

  • Deposited: 2017-07-23 Released: 2018-10-24
  • Deposition Author(s): Thirawatananond, P., Gabelli, S.B.
  • Funding Organization(s): AHN, National Institutes of Health/National Cancer Institute (NIH/NCI), Department of Defense (DOD, United States)

Experimental Data Snapshot

  • Resolution: 2.30 Å
  • R-Value Free: 0.277
  • R-Value Work: 0.207
  • R-Value Observed: 0.210

wwPDB Validation   3D Report Full Report

This is version 1.6 of the entry. See complete history


Structural analyses of NudT16-ADP-ribose complexes direct rational design of mutants with improved processing of poly(ADP-ribosyl)ated proteins.

Thirawatananond, P.McPherson, R.L.Malhi, J.Nathan, S.Lambrecht, M.J.Brichacek, M.Hergenrother, P.J.Leung, A.K.L.Gabelli, S.B.

(2019) Sci Rep 9: 5940-5940

  • DOI: https://doi.org/10.1038/s41598-019-39491-w
  • Primary Citation of Related Structures:
    5VY2, 5W6X, 5W6Z, 5WJI, 6B09

  • PubMed Abstract:

    ADP-ribosylation is a post-translational modification that occurs on chemically diverse amino acids, including aspartate, glutamate, lysine, arginine, serine and cysteine on proteins and is mediated by ADP-ribosyltransferases, including a subset commonly known as poly(ADP-ribose) polymerases. ADP-ribose can be conjugated to proteins singly as a monomer or in polymeric chains as poly(ADP-ribose). While ADP-ribosylation can be reversed by ADP-ribosylhydrolases, this protein modification can also be processed to phosphoribosylation by enzymes possessing phosphodiesterase activity, such as snake venom phosphodiesterase, mammalian ectonucleotide pyrophosphatase/phosphodiesterase 1, Escherichia coli RppH, Legionella pneumophila Sde and Homo sapiens NudT16 (HsNudT16). Our studies here sought to utilize X-ray crystallographic structures of HsNudT16 in complex with monomeric and dimeric ADP-ribose in identifying the active site for binding and processing free and protein-conjugated ADP-ribose into phosphoribose forms. These structural data guide rational design of mutants that widen the active site to better accommodate protein-conjugated ADP-ribose. We identified that several HsNudT16 mutants (Δ17, F36A, and F61S) have reduced activity for free ADP-ribose, similar processing ability against protein-conjugated mono(ADP-ribose), but improved catalytic efficiency for protein-conjugated poly(ADP-ribose). These HsNudT16 variants may, therefore, provide a novel tool to investigate different forms of ADP-ribose.

  • Organizational Affiliation

    Department of Biophysics and Biophysical Chemistry, Johns Hopkins University School of Medicine, Baltimore, MD, 21205, USA.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
U8 snoRNA-decapping enzyme
A, B
195Homo sapiensMutation(s): 2
Gene Names: NUDT16
EC: (PDB Primary Data), (PDB Primary Data)
UniProt & NIH Common Fund Data Resources
Find proteins for Q96DE0 (Homo sapiens)
Explore Q96DE0
Go to UniProtKB:  Q96DE0
GTEx:  ENSG00000198585
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ96DE0
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 2.30 Å
  • R-Value Free: 0.277
  • R-Value Work: 0.207
  • R-Value Observed: 0.210
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 113.779α = 90
b = 46.975β = 110.43
c = 72.313γ = 90
Software Package:
Software NamePurpose
DENZOdata collection
SCALEPACKdata scaling
PDB_EXTRACTdata extraction
HKL-3000data reduction

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
AHNUnited States--
National Institutes of Health/National Cancer Institute (NIH/NCI)United StatesCA062924
Department of Defense (DOD, United States)United StatesBC151831

Revision History  (Full details and data files)

  • Version 1.0: 2018-10-24
    Type: Initial release
  • Version 1.1: 2019-02-20
    Changes: Author supporting evidence, Data collection
  • Version 1.2: 2019-06-05
    Changes: Data collection, Database references
  • Version 1.3: 2019-12-04
    Changes: Author supporting evidence
  • Version 1.4: 2020-01-08
    Changes: Author supporting evidence
  • Version 1.5: 2024-03-13
    Changes: Data collection, Database references
  • Version 1.6: 2024-04-03
    Changes: Refinement description
