5WFX | pdb_00005wfx

Structural basis for the interaction of 14-3-3beta with Tricarboxylic Acid Cycle intermediate Malate

PDB DOI: https://doi.org/10.2210/pdb5WFX/pdb

Classification: PROTEIN TRANSPORT
Organism(s): Mus musculus
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2017-07-12 Released: 2018-05-16
Deposition Author(s): Hou, Z.Q.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.65 Å
R-Value Free:
0.231 (Depositor), 0.230 (DCC)
R-Value Work:
0.200 (Depositor), 0.200 (DCC)
R-Value Observed:
0.202 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.1 of the entry. See complete history.

Literature

Structural basis for the interaction of 14-3-3 beta withTricarboxylic Acid Cycle intermediate Malate

Hou, Z.Q., Su, L.J., Liu, X.Y.

To be published.

Macromolecule Content

Total Structure Weight: 56.24 kDa
Atom Count: 4,335
Modeled Residue Count: 464
Deposited Residue Count: 492
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
14-3-3 protein beta/alpha	A, B	246	Mus musculus	Mutation(s): 0 Gene Names: Ywhab
UniProt & NIH Common Fund Data Resources
Find proteins for Q9CQV8 (Mus musculus) Explore Q9CQV8 Go to UniProtKB: Q9CQV8
IMPC: MGI:1891917
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q9CQV8
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.65 Å
R-Value Free: 0.231 (Depositor), 0.230 (DCC)
R-Value Work: 0.200 (Depositor), 0.200 (DCC)
R-Value Observed: 0.202 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 59.93	α = 90
b = 87.79	β = 90
c = 124.044	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
DENZO	data reduction
SCALEPACK	data scaling
PHENIX	phasing

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2018-05-16

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2018-05-16
Type: Initial release
Version 1.1: 2023-10-04
Changes: Data collection, Database references, Refinement description
