5WCC

Crystal structure of the broadly neutralizing Influenza A antibody VRC 315 02-1F07 Fab.


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.461 Å
  • R-Value Free: 0.240
  • R-Value Work: 0.203

wwPDB Validation 3D Report Full Report


This is version 1.0 of the entry. See complete history

Literature

Preferential induction of cross-group influenza A hemagglutinin stem-specific memory B cells after H7N9 immunization in humans.

Andrews, S.F.Joyce, M.G.Chambers, M.J.Gillespie, R.A.Kanekiyo, M.Leung, K.Yang, E.S.Tsybovsky, Y.Wheatley, A.K.Crank, M.C.Boyington, J.C.Prabhakaran, M.S.Narpala, S.R.Chen, X.Bailer, R.T.Chen, G.Coates, E.Kwong, P.D.Koup, R.A.Mascola, J.R.Graham, B.S.Ledgerwood, J.E.McDermott, A.B.

(2017) Sci Immunol 2: --

  • DOI: 10.1126/sciimmunol.aan2676
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Antigenic drift and shift of influenza strains underscore the need for broadly protective influenza vaccines. One strategy is to design immunogens that elicit B cell responses against conserved epitopes on the hemagglutinin (HA) stem. To better under ...

    Antigenic drift and shift of influenza strains underscore the need for broadly protective influenza vaccines. One strategy is to design immunogens that elicit B cell responses against conserved epitopes on the hemagglutinin (HA) stem. To better understand the elicitation of HA stem-targeted B cells to group 1 and group 2 influenza subtypes, we compared the memory B cell response to group 2 H7N9 and group 1 H5N1 vaccines in humans. Upon H7N9 vaccination, almost half of the HA stem-specific response recognized the group 1 and group 2 subtypes, whereas the response to H5N1 was largely group 1-specific. Immunoglobulin repertoire analysis of HA-specific B cells indicated that the H7N9 and H5N1 vaccines induced genetically similar cross-group HA stem-binding B cells, albeit at a much higher frequency upon H7N9 vaccination. These data suggest that a group 2-based stem immunogen could prove more effective than a group 1 immunogen at eliciting broad cross-group protection in humans.


    Organizational Affiliation

    Vaccine Research Center, National Institute of Allergy and Infectious Diseases, National Institutes of Health, Bethesda, MD 20892, USA. adrian.mcdermott@nih.gov sarah.andrews2@nih.gov.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
VRC 315 02-1F07 Fab Heavy chain
H, A
227N/AMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
VRC 315 02-1F07 Fab Light chain
L, B
217N/AMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download SDF File
Download CCD File
A, B, L
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
GOL
Query on GOL

Download SDF File
Download CCD File
L
GLYCEROL
GLYCERIN; PROPANE-1,2,3-TRIOL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
 Ligand Interaction
15P
Query on 15P

Download SDF File
Download CCD File
B, L
POLYETHYLENE GLYCOL (N=34)
PEG 1500
C69 H140 O35
VUYXVWGKCKTUMF-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.461 Å
  • R-Value Free: 0.240
  • R-Value Work: 0.203
  • Space Group: C 1 2 1
Unit Cell:
Length (Å)Angle (°)
a = 179.217α = 90.00
b = 70.581β = 111.86
c = 94.543γ = 90.00
Software Package:
Software NamePurpose
PHENIXrefinement
PHASERphasing
HKL-2000data scaling
HKL-2000data reduction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2017-12-13
    Type: Initial release
