5W1Y | pdb_00005w1y

SETD8 in complex with a covalent inhibitor

PDB DOI: https://doi.org/10.2210/pdb5W1Y/pdb

Classification: TRANSFERASE/TRANSFERASE INHIBITOR
Organism(s): Homo sapiens
Expression System: Escherichia coli BL21
Mutation(s): Yes

Deposited: 2017-06-05 Released: 2017-06-21
Deposition Author(s): Tempel, W., Yu, W., Li, Y., Blum, G., Luo, M., Pittella-Silva, F., Bountra, C., Arrowsmith, C.H., Edwards, A.M., Brown, P.J., Structural Genomics Consortium (SGC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free:
0.237 (Depositor), 0.251 (DCC)
R-Value Work:
0.201 (Depositor), 0.212 (DCC)
R-Value Observed:
0.203 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.3 of the entry. See complete history.

Literature

SETD8 in complex with a covalent inhibitor

Tempel, W., Yu, W., Li, Y., Bountra, C., Arrowsmith, C.H., Edwards, A.M., Brown, P.J., Structural Genomics Consortium (SGC)

To be published.

Macromolecule Content

Total Structure Weight: 38.28 kDa
Atom Count: 2,835
Modeled Residue Count: 314
Deposited Residue Count: 332
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
N-lysine methyltransferase KMT5A	A, B	166	Homo sapiens	Mutation(s): 1 Gene Names: KMT5A, PRSET7, SET07, SET8, SETD8 EC: 2.1.1 (PDB Primary Data), 2.1.1.43 (PDB Primary Data), 2.1.1.361 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for Q9NQR1 (Homo sapiens) Explore Q9NQR1 Go to UniProtKB: Q9NQR1
PHAROS: Q9NQR1 GTEx: ENSG00000183955
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9NQR1
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
9SV (Subject of Investigation/LOI) Query on 9SV Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain S [auth B] MOL2 format, chain C [auth A] MOL2 format, chain S [auth B] mmCIF format, chain C [auth A] mmCIF format, chain S [auth B]	C [auth A], S [auth B]	2-(4-methylpiperazin-1-yl)-3-(phenylsulfanyl)naphthalene-1,4-dione C₂₁ H₂₀ N₂ O₂ S MJTBKNZEOWNOFN-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain S [auth B] Interactions & Density Focus chain C [auth A] Focus chain S [auth B]
UNX Query on UNX Download:Ideal Coordinates CCD File SDF format, chain AA [auth B] SDF format, chain BA [auth B] SDF format, chain CA [auth B] SDF format, chain D [auth A] SDF format, chain DA [auth B] SDF format, chain E [auth A] SDF format, chain EA [auth B] SDF format, chain F [auth A] SDF format, chain FA [auth B] SDF format, chain G [auth A] SDF format, chain GA [auth B] SDF format, chain H [auth A] SDF format, chain HA [auth B] SDF format, chain I [auth A] SDF format, chain IA [auth B] SDF format, chain J [auth A] SDF format, chain JA [auth B] SDF format, chain K [auth A] SDF format, chain KA [auth B] SDF format, chain L [auth A] SDF format, chain LA [auth B] SDF format, chain M [auth A] SDF format, chain MA [auth B] SDF format, chain N [auth A] SDF format, chain NA [auth B] SDF format, chain O [auth A] SDF format, chain P [auth A] SDF format, chain Q [auth A] SDF format, chain R [auth A] SDF format, chain T [auth B] SDF format, chain U [auth B] SDF format, chain V [auth B] SDF format, chain W [auth B] SDF format, chain X [auth B] SDF format, chain Y [auth B] SDF format, chain Z [auth B] MOL2 format, chain AA [auth B] MOL2 format, chain BA [auth B] MOL2 format, chain CA [auth B] MOL2 format, chain D [auth A] MOL2 format, chain DA [auth B] MOL2 format, chain E [auth A] MOL2 format, chain EA [auth B] MOL2 format, chain F [auth A] MOL2 format, chain FA [auth B] MOL2 format, chain G [auth A] MOL2 format, chain GA [auth B] MOL2 format, chain H [auth A] MOL2 format, chain HA [auth B] MOL2 format, chain I [auth A] MOL2 format, chain IA [auth B] MOL2 format, chain J [auth A] MOL2 format, chain JA [auth B] MOL2 format, chain K [auth A] MOL2 format, chain KA [auth B] MOL2 format, chain L [auth A] MOL2 format, chain LA [auth B] MOL2 format, chain M [auth A] MOL2 format, chain MA [auth B] MOL2 format, chain N [auth A] MOL2 format, chain NA [auth B] MOL2 format, chain O [auth A] MOL2 format, chain P [auth A] MOL2 format, chain Q [auth A] MOL2 format, chain R [auth A] MOL2 format, chain T [auth B] MOL2 format, chain U [auth B] MOL2 format, chain V [auth B] MOL2 format, chain W [auth B] MOL2 format, chain X [auth B] MOL2 format, chain Y [auth B] MOL2 format, chain Z [auth B] mmCIF format, chain AA [auth B] mmCIF format, chain BA [auth B] mmCIF format, chain CA [auth B] mmCIF format, chain D [auth A] mmCIF format, chain DA [auth B] mmCIF format, chain E [auth A] mmCIF format, chain EA [auth B] mmCIF format, chain F [auth A] mmCIF format, chain FA [auth B] mmCIF format, chain G [auth A] mmCIF format, chain GA [auth B] mmCIF format, chain H [auth A] mmCIF format, chain HA [auth B] mmCIF format, chain I [auth A] mmCIF format, chain IA [auth B] mmCIF format, chain J [auth A] mmCIF format, chain JA [auth B] mmCIF format, chain K [auth A] mmCIF format, chain KA [auth B] mmCIF format, chain L [auth A] mmCIF format, chain LA [auth B] mmCIF format, chain M [auth A] mmCIF format, chain MA [auth B] mmCIF format, chain N [auth A] mmCIF format, chain NA [auth B] mmCIF format, chain O [auth A] mmCIF format, chain P [auth A] mmCIF format, chain Q [auth A] mmCIF format, chain R [auth A] mmCIF format, chain T [auth B] mmCIF format, chain U [auth B] mmCIF format, chain V [auth B] mmCIF format, chain W [auth B] mmCIF format, chain X [auth B] mmCIF format, chain Y [auth B] mmCIF format, chain Z [auth B]	AA [auth B] BA [auth B] CA [auth B] D [auth A] DA [auth B] AA [auth B], BA [auth B], CA [auth B], D [auth A], DA [auth B], E [auth A], EA [auth B], F [auth A], FA [auth B], G [auth A], GA [auth B], H [auth A], HA [auth B], I [auth A], IA [auth B], J [auth A], JA [auth B], K [auth A], KA [auth B], L [auth A], LA [auth B], M [auth A], MA [auth B], N [auth A], NA [auth B], O [auth A], P [auth A], Q [auth A], R [auth A], T [auth B], U [auth B], V [auth B], W [auth B], X [auth B], Y [auth B], Z [auth B]	UNKNOWN ATOM OR ION X		Interactions Focus chain AA [auth B] Focus chain BA [auth B] Focus chain CA [auth B] Focus chain D [auth A] Focus chain DA [auth B] Focus chain E [auth A] Focus chain EA [auth B] Focus chain F [auth A] Focus chain FA [auth B] Focus chain G [auth A] Focus chain GA [auth B] Focus chain H [auth A] Focus chain HA [auth B] Focus chain I [auth A] Focus chain IA [auth B] Focus chain J [auth A] Focus chain JA [auth B] Focus chain K [auth A] Focus chain KA [auth B] Focus chain L [auth A] Focus chain LA [auth B] Focus chain M [auth A] Focus chain MA [auth B] Focus chain N [auth A] Focus chain NA [auth B] Focus chain O [auth A] Focus chain P [auth A] Focus chain Q [auth A] Focus chain R [auth A] Focus chain T [auth B] Focus chain U [auth B] Focus chain V [auth B] Focus chain W [auth B] Focus chain X [auth B] Focus chain Y [auth B] Focus chain Z [auth B] Interactions & Density Focus chain AA [auth B] Focus chain BA [auth B] Focus chain CA [auth B] Focus chain D [auth A] Focus chain DA [auth B] Focus chain E [auth A] Focus chain EA [auth B] Focus chain F [auth A] Focus chain FA [auth B] Focus chain G [auth A] Focus chain GA [auth B] Focus chain H [auth A] Focus chain HA [auth B] Focus chain I [auth A] Focus chain IA [auth B] Focus chain J [auth A] Focus chain JA [auth B] Focus chain K [auth A] Focus chain KA [auth B] Focus chain L [auth A] Focus chain LA [auth B] Focus chain M [auth A] Focus chain MA [auth B] Focus chain N [auth A] Focus chain NA [auth B] Focus chain O [auth A] Focus chain P [auth A] Focus chain Q [auth A] Focus chain R [auth A] Focus chain T [auth B] Focus chain U [auth B] Focus chain V [auth B] Focus chain W [auth B] Focus chain X [auth B] Focus chain Y [auth B] Focus chain Z [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free: 0.237 (Depositor), 0.251 (DCC)
R-Value Work: 0.201 (Depositor), 0.212 (DCC)
R-Value Observed: 0.203 (Depositor)

Diffraction Data:

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 58.348	α = 90
b = 39.788	β = 90
c = 131.895	γ = 90

Software Package:

Software Name	Purpose
Aimless	data scaling
REFMAC	refinement
PDB_EXTRACT	data extraction
XDS	data reduction
PHASER	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2017-06-21

Deposition Author(s):

Structural Genomics Consortium (SGC)

Revision History (Full details and data files)

Version 1.0: 2017-06-21
Type: Initial release
Version 1.1: 2017-07-12
Changes: Refinement description, Structure summary
Version 1.2: 2023-10-04
Changes: Advisory, Data collection, Database references, Refinement description
Version 1.3: 2024-11-06
Changes: Structure summary
