Crystal structure of hFA9 EGF repeat with O-glucose trisaccharide

Experimental Data Snapshot

  • Resolution: 2.20 Å
  • R-Value Free: 0.259
  • R-Value Work: 0.212
  • R-Value Observed: 0.214

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report

This is version 2.1 of the entry. See complete history


O-Glycosylation modulates the stability of epidermal growth factor-like repeats and thereby regulates Notch trafficking

Takeuchi, H.Yu, H.Hao, H.Takeuchi, M.Ito, A.Li, H.Haltiwanger, R.S.

(2017) J Biol Chem 292: 15964-15973

  • DOI: https://doi.org/10.1074/jbc.M117.800102
  • Primary Citation of Related Structures:

  • PubMed Abstract:

    Glycosylation in the endoplasmic reticulum (ER) is closely associated with protein folding and quality control. We recently described a non-canonical ER quality control mechanism for folding of thrombospondin type 1 repeats by protein O -fucosyltransferase 2 (POFUT2). Epidermal growth factor-like (EGF) repeats are also small cysteine-rich protein motifs that can be O -glycosylated by several ER-localized enzymes, including protein O -glucosyltransferase 1 (POGLUT1) and POFUT1. Both POGLUT1 and POFUT1 modify the Notch receptor on multiple EGF repeats and are essential for full Notch function. The fact that POGLUT1 and POFUT1 can distinguish between folded and unfolded EGF repeats raised the possibility that they participate in a quality control pathway for folding of EGF repeats in proteins such as Notch. Here, we demonstrate that cell-surface expression of endogenous Notch1 in HEK293T cells is dependent on the presence of POGLUT1 and POFUT1 in an additive manner. In vitro unfolding assays reveal that addition of O -glucose or O -fucose stabilizes a single EGF repeat and that addition of both O -glucose and O -fucose enhances stability in an additive manner. Finally, we solved the crystal structure of a single EGF repeat covalently modified by a full O -glucose trisaccharide at 2.2 Å resolution. The structure reveals that the glycan fills up a surface groove of the EGF with multiple contacts with the protein, providing a chemical basis for the stabilizing effects of the glycans. Taken together, this work suggests that O -fucose and O -glucose glycans cooperatively stabilize individual EGF repeats through intramolecular interactions, thereby regulating Notch trafficking in cells.

  • Organizational Affiliation

    From the Complex Carbohydrate Research Center, University of Georgia, Athens, Georgia 30602.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Coagulation factor IXA [auth B],
B [auth A],
50Homo sapiensMutation(s): 0
Gene Names: F9
UniProt & NIH Common Fund Data Resources
Find proteins for P00740 (Homo sapiens)
Explore P00740
Go to UniProtKB:  P00740
GTEx:  ENSG00000101981
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00740
Glycosylation Sites: 1Go to GlyGen: P00740-1
Sequence Annotations
  • Reference Sequence


Entity ID: 2
MoleculeChains Length2D Diagram Glycosylation3D Interactions
D, E, F
Glycosylation Resources
GlyTouCan:  G41179DF
GlyCosmos:  G41179DF
GlyGen:  G41179DF
Experimental Data & Validation

Experimental Data

  • Resolution: 2.20 Å
  • R-Value Free: 0.259
  • R-Value Work: 0.212
  • R-Value Observed: 0.214
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 92.417α = 90
b = 46.84β = 92.58
c = 37.259γ = 90
Software Package:
Software NamePurpose
XDSdata reduction
SCALAdata scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2017-08-09
    Type: Initial release
  • Version 1.1: 2018-02-28
    Changes: Database references
  • Version 2.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Advisory, Atomic model, Data collection, Derived calculations, Non-polymer description, Structure summary
  • Version 2.1: 2023-10-04
    Changes: Data collection, Database references, Refinement description, Structure summary
