5VXT | pdb_00005vxt

Crystal structure of catechol 1,2-dioxygenase from Burkholderia ambifaria

PDB DOI: https://doi.org/10.2210/pdb5VXT/pdb

Classification: OXIDOREDUCTASE
Organism(s): Burkholderia ambifaria MC40-6
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2017-05-24 Released: 2017-06-14
Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.75 Å
R-Value Free:
0.224 (Depositor), 0.226 (DCC)
R-Value Work:
0.186 (Depositor), 0.186 (DCC)
R-Value Observed:
0.187 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Crystal structure of catechol 1,2-dioxygenase from Burkholderia ambifaria

Phan, J.N., Dranow, D.M., Lorimer, D., Edwards, T.E.

To be published.

Macromolecule Content

Total Structure Weight: 72 kDa
Atom Count: 5,548
Modeled Residue Count: 623
Deposited Residue Count: 650
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Catechol 1,2-dioxygenase	A, B	325	Burkholderia ambifaria MC40-6	Mutation(s): 0 Gene Names: BamMC406_6300 EC: 1.13.11.1
UniProt
Find proteins for B1Z4S0 (Burkholderia ambifaria (strain MC40-6)) Explore B1Z4S0 Go to UniProtKB: B1Z4S0
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	B1Z4S0
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 5 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
PTY Query on PTY Download:Ideal Coordinates CCD File SDF format, chain I [auth B] SDF format, chain C [auth A] MOL2 format, chain I [auth B] MOL2 format, chain C [auth A] mmCIF format, chain I [auth B] mmCIF format, chain C [auth A]	C [auth A], I [auth B]	PHOSPHATIDYLETHANOLAMINE C₄₀ H₈₀ N O₈ P NJGIRBISCGPRPF-KXQOOQHDSA-N		Interactions Focus chain C [auth A] Focus chain I [auth B] Interactions & Density Focus chain C [auth A] Focus chain I [auth B]
CAQ Query on CAQ Download:Ideal Coordinates CCD File SDF format, chain K [auth B] SDF format, chain E [auth A] MOL2 format, chain K [auth B] MOL2 format, chain E [auth A] mmCIF format, chain K [auth B] mmCIF format, chain E [auth A]	E [auth A], K [auth B]	CATECHOL C₆ H₆ O₂ YCIMNLLNPGFGHC-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain K [auth B] Interactions & Density Focus chain E [auth A] Focus chain K [auth B]
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain M [auth B] SDF format, chain L [auth B] SDF format, chain G [auth A] SDF format, chain F [auth A] MOL2 format, chain M [auth B] MOL2 format, chain L [auth B] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] mmCIF format, chain M [auth B] mmCIF format, chain L [auth B] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A]	F [auth A], G [auth A], L [auth B], M [auth B]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain F [auth A] Focus chain G [auth A] Focus chain L [auth B] Focus chain M [auth B] Interactions & Density Focus chain F [auth A] Focus chain G [auth A] Focus chain L [auth B] Focus chain M [auth B]
FE Query on FE Download:Ideal Coordinates CCD File SDF format, chain J [auth B] SDF format, chain D [auth A] MOL2 format, chain J [auth B] MOL2 format, chain D [auth A] mmCIF format, chain J [auth B] mmCIF format, chain D [auth A]	D [auth A], J [auth B]	FE (III) ION Fe VTLYFUHAOXGGBS-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain J [auth B] Interactions & Density Focus chain D [auth A] Focus chain J [auth B]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain H [auth A] MOL2 format, chain H [auth A] mmCIF format, chain H [auth A]	H [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain H [auth A] Interactions & Density Focus chain H [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.75 Å
R-Value Free: 0.224 (Depositor), 0.226 (DCC)
R-Value Work: 0.186 (Depositor), 0.186 (DCC)
R-Value Observed: 0.187 (Depositor)

Diffraction Data:

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 66.08	α = 90
b = 52.2	β = 106.62
c = 105.19	γ = 90

Software Package:

Software Name	Purpose
XSCALE	data scaling
MOLREP	phasing
PHENIX	refinement
PDB_EXTRACT	data extraction
XDS	data reduction
Coot	model building

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2017-06-14

Deposition Author(s):

Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Revision History (Full details and data files)

Version 1.0: 2017-06-14
Type: Initial release
Version 1.1: 2023-10-04
Changes: Data collection, Database references, Derived calculations, Refinement description
