5VI9 | pdb_00005vi9

Crystal structure of Protein Kinase A in complex with the PKI peptide and Aminobenzothiazole based inhibitors


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.95 Å
  • R-Value Free:
    0.256 (Depositor), 0.260 (DCC)
  • R-Value Work:
    0.206 (Depositor), 0.210 (DCC)
  • R-Value Observed:
    0.209 (Depositor)

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment

Created with Raphaël 2.3.0Worse 01 BetterLigand structure goodness of fit to experimental dataBest fitted 9D4Click on this verticalbar to view details

This is version 1.3 of the entry. See complete history


Literature

Design of Aminobenzothiazole Inhibitors of Rho Kinases 1 and 2 by Using Protein Kinase A as a Structure Surrogate.

Judge, R.A.Vasudevan, A.Scott, V.E.Simler, G.H.Pratt, S.D.Namovic, M.T.Putman, C.B.Aguirre, A.Stoll, V.S.Mamo, M.Swann, S.I.Cassar, S.C.Faltynek, C.R.Kage, K.L.Boyce-Rustay, J.M.Hobson, A.D.

(2018) Chembiochem 19: 613-621

  • DOI: https://doi.org/10.1002/cbic.201700547
  • Primary Citation of Related Structures:
    5VHB, 5VI9, 5VIB

  • PubMed Abstract:

    We describe the design, synthesis, and structure-activity relationships (SARs) of a series of 2-aminobenzothiazole inhibitors of Rho kinases (ROCKs) 1 and 2, which were optimized to low nanomolar potencies by use of protein kinase A (PKA) as a structure surrogate to guide compound design. A subset of these molecules also showed robust activity in a cell-based myosin phosphatase assay and in a mechanical hyperalgesia in vivo pain model.


  • Organizational Affiliation

    AbbVie, Inc., 1 North Waukegan Road, North Chicago, IL, 60064, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
cAMP-dependent protein kinase catalytic subunit alpha351Bos taurusMutation(s): 0
Gene Names: PRKACA
EC: 2.7.11.11
UniProt
Find proteins for P00517 (Bos taurus)
Explore P00517
Go to UniProtKB:  P00517
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00517
Sequence Annotations
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
PKI peptide18Bos taurusMutation(s): 0
UniProt
Find proteins for Q3SX13 (Bos taurus)
Explore Q3SX13
Go to UniProtKB:  Q3SX13
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ3SX13
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
9D4
Query on 9D4

Download Ideal Coordinates CCD File
C [auth A]N-[(3-fluorophenyl)methyl]-6-(pyridin-4-yl)-1,3-benzothiazol-2-amine
C19 H14 F N3 S
KCSSSFZRQGBLKE-UHFFFAOYSA-N
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
TPO
Query on TPO
A
L-PEPTIDE LINKINGC4 H10 N O6 PTHR
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.95 Å
  • R-Value Free:  0.256 (Depositor), 0.260 (DCC)
  • R-Value Work:  0.206 (Depositor), 0.210 (DCC)
  • R-Value Observed: 0.209 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 70.558α = 90
b = 72.855β = 90
c = 77.806γ = 90
Software Package:
Software NamePurpose
BUSTERrefinement
Aimlessdata scaling
PDB_EXTRACTdata extraction
XDSdata reduction
MOLREPphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment

Created with Raphaël 2.3.0Worse 01 BetterLigand structure goodness of fit to experimental dataBest fitted 9D4Click on this verticalbar to view details

Entry History

Deposition Data

  • Released Date: 2018-01-31
  • Deposition Author(s): Judge, R.A.

Revision History  (Full details and data files)

  • Version 1.0: 2018-01-31
    Type: Initial release
  • Version 1.1: 2018-02-14
    Changes: Database references
  • Version 1.2: 2018-04-04
    Changes: Data collection, Database references
  • Version 1.3: 2024-11-20
    Changes: Data collection, Database references, Structure summary
