5VCJ

Structure of alpha-galactosylphytosphingosine bound by CD1d and in complex with the Va14Vb8.2 TCR


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.16 Å
  • R-Value Free: 0.248
  • R-Value Work: 0.189
  • R-Value Observed: 0.192

wwPDB Validation   3D Report Full Report



Literature

Enhancing T cell responses and tumour immunity by vaccination with peptides conjugated to a weak NKT cell agonist.

Compton, B.J.Farrand, K.J.Tang, C.W.Osmond, T.L.Speir, M.Authier-Hall, A.Wang, J.Ferguson, P.M.Chan, S.T.S.Anderson, R.J.Cooney, T.R.Hayman, C.M.Williams, G.M.Brimble, M.A.Brooks, C.R.Yong, L.K.Metelitsa, L.S.Zajonc, D.M.Godfrey, D.I.Gasser, O.Weinkove, R.Painter, G.F.Hermans, I.F.

(2019) Org Biomol Chem 17: 1225-1237

  • DOI: 10.1039/c8ob02982b
  • Primary Citation of Related Structures:
    5VCJ

  • PubMed Abstract:
  • Activated NKT cells can stimulate antigen-presenting cells leading to enhanced peptide antigen-specific immunity. However, administration of potent NKT cell agonists like α-galactosylceramide (α-GalCer) can be associated with release of high levels o ...

    Activated NKT cells can stimulate antigen-presenting cells leading to enhanced peptide antigen-specific immunity. However, administration of potent NKT cell agonists like α-galactosylceramide (α-GalCer) can be associated with release of high levels of cytokines, and in some situations, hepatotoxicity. Here we show that it is possible to provoke sufficient NKT cell activity to stimulate strong antigen-specific T cell responses without these unwanted effects. This was achieved by chemically conjugating antigenic peptides to α-galactosylphytosphingosine (α-GalPhs), an NKT cell agonist with very weak activity based on structural characterisation and biological assays. Conjugation improved delivery to antigen-presenting cells in vivo, while use of a cathepsin-sensitive linker to release the α-GalPhs and peptide within the same cell promoted strong T cell activation and therapeutic anti-tumour responses in mice. The conjugates activated human NKT cells and enhanced human T cell responses to a viral peptide in vitro. Accordingly, we have demonstrated a means to safely exploit the immunostimulatory properties of NKT cells to enhance T cell activation for virus- and tumour-specific immunity.


    Organizational Affiliation

    The Ferrier Research Institute, Victoria University of Wellington, Lower Hutt, New Zealand. gavin.painter@vuw.ac.nz.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Antigen-presenting glycoprotein CD1d1A285Mus musculusMutation(s): 1
Gene Names: Cd1d1Cd1.1
Find proteins for P11609 (Mus musculus)
Explore P11609
Go to UniProtKB:  P11609
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
Beta-2-microglobulinB99Mus musculusMutation(s): 0
Gene Names: B2m
Find proteins for P01887 (Mus musculus)
Explore P01887
Go to UniProtKB:  P01887
NIH Common Fund Data Resources
IMPC  MGI:88127
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetailsImage
Chimeric TCR Valpha14/Jalpha18 chain (mouse variable domain, human constant domain)C209Mus musculusHomo sapiens
This entity is chimeric
Mutation(s): 0
Gene Names: Trav11Trav11d
Find proteins for A0A0B4J1J9 (Mus musculus)
Explore A0A0B4J1J9
Go to UniProtKB:  A0A0B4J1J9
Find proteins for K7N5M3 (Homo sapiens)
Explore K7N5M3
Go to UniProtKB:  K7N5M3
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 4
MoleculeChainsSequence LengthOrganismDetailsImage
Chimeric TCR Vbeta8.2 chain (mouse variable domain, human constant domain)D241Mus musculusHomo sapiens
This entity is chimeric
Mutation(s): 0
Protein Feature View
Expand
  • Reference Sequence
Oligosaccharides

Help

Entity ID: 5
MoleculeChainsChain Length2D Diagram Glycosylation3D Interactions
alpha-D-mannopyranose-(1-3)-[alpha-D-mannopyranose-(1-6)]beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-[alpha-L-fucopyranose-(1-6)]2-acetamido-2-deoxy-beta-D-glucopyranose
E
6 N-Glycosylation Oligosaccharides Interaction
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
N57
Query on N57

Download Ideal Coordinates CCD File
A
(2S,3S,4R)-2-amino-3,4-dihydroxyoctadecyl alpha-D-galactopyranoside
C24 H49 N O8
CBKONJDETAETLR-MKQNOXKVSA-N
 Ligand Interaction
PLM
Query on PLM

Download Ideal Coordinates CCD File
A
PALMITIC ACID
C16 H32 O2
IPCSVZSSVZVIGE-UHFFFAOYSA-N
 Ligand Interaction
NAG
Query on NAG

Download Ideal Coordinates CCD File
A
2-acetamido-2-deoxy-beta-D-glucopyranose
C8 H15 N O6
OVRNDRQMDRJTHS-FMDGEEDCSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.16 Å
  • R-Value Free: 0.248
  • R-Value Work: 0.189
  • R-Value Observed: 0.192
  • Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 79.261α = 90
b = 191.611β = 90
c = 151.249γ = 90
Software Package:
Software NamePurpose
HKL-2000data reduction
SCALEPACKdata scaling
PHASERphasing
REFMACrefinement
PDB_EXTRACTdata extraction
HKLdata reduction

Structure Validation

View Full Validation Report



Entry History

Deposition Data

  • Deposited Date: 2017-03-31
  • Released Date: 2018-04-04
  • Deposition Author(s): Wang, J., Zajonc, D.M.

Revision History

  • Version 1.0: 2018-04-04
    Type: Initial release
  • Version 1.1: 2019-04-17
    Changes: Data collection, Database references
  • Version 2.0: 2019-05-15
    Changes: Advisory, Atomic model, Data collection, Derived calculations, Non-polymer description, Structure summary
  • Version 3.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Atomic model, Data collection, Derived calculations, Structure summary
