5V21

Crystal structure of human SETD2 SET-domain in complex with H3K36M peptide and SAM

  • Classification: TRANSFERASE
  • Organism(s): Homo sapiens
  • Expression System: Escherichia coli
  • Mutation(s): No

  • Deposited: 2017-03-02 Released: 2017-03-22
  • Deposition Author(s): Zhang, Y., Tong, L.
  • Funding Organization(s): National Institutes of Health/Office of the Director, National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.42 Å
  • R-Value Free: 0.269
  • R-Value Work: 0.204
  • R-Value Observed: 0.207

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.4 of the entry. See complete history.


Literature

Molecular basis for the role of oncogenic histone mutations in modulating H3K36 methylation.

Zhang, Y., Shan, C.M., Wang, J., Bao, K., Tong, L., Jia, S.

(2017) Sci Rep 7: 43906-43906

  • DOI: 10.1038/srep43906
  • Primary Citation of Related Structures:
    5V21, 5V22

  • PubMed Abstract:

    • Histone H3 lysine 36 methylation (H3K36me) is critical for epigenetic regulation and mutations at or near H3K36 are associated with distinct types of cancers. H3K36M dominantly inhibits H3K36me on wild-type histones, whereas H3G34R/V selectively affects H3K36me on the same histone tail ...

    Histone H3 lysine 36 methylation (H3K36me) is critical for epigenetic regulation and mutations at or near H3K36 are associated with distinct types of cancers. H3K36M dominantly inhibits H3K36me on wild-type histones, whereas H3G34R/V selectively affects H3K36me on the same histone tail. Here we report the crystal structures of SETD2 SET domain in complex with an H3K36M peptide and SAM or SAH. There are large conformational changes in the substrate binding regions of the SET domain, and the K36M residue interacts with the catalytic pocket of SETD2. H3G34 is surrounded by a very narrow tunnel, which excludes larger amino acid side chains. H3P38 is in the trans configuration, and the cis configuration is incompatible with SETD2 binding. Finally, mutations of H3G34 or H3P38 alleviate the inhibitory effects of H3K36M on H3K36me, demonstrating that the stable interaction of H3K36M with SETD2 is critical for its inhibitory effects.

    Organizational Affiliation:

    Department of Biological Sciences, Columbia University, New York, NY 10027, USA.



Macromolecules
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Histone-lysine N-methyltransferase SETD2A297Homo sapiensMutation(s): 0
Gene Names: SETD2, HIF1, HYPB, KIAA1732, KMT3A, SET2, HSPC069
EC: 2.1.1.43 (PDB Primary Data), 2.1.1.359 (UniProt), 2.1.1 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for Q9BYW2 (Homo sapiens)
Explore Q9BYW2
Go to UniProtKB:  Q9BYW2
PHAROS:  Q9BYW2
GTEx:  ENSG00000181555
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9BYW2
Protein Feature View
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
Histone H3K36M peptideB15Homo sapiensMutation(s): 0
Gene Names:
UniProt & NIH Common Fund Data Resources
Find proteins for P68431 (Homo sapiens)
Explore P68431
Go to UniProtKB:  P68431
PHAROS:  P68431
GTEx:  ENSG00000197409 ENSG00000197153 ENSG00000278828 ENSG00000275714 ENSG00000273983 ENSG00000274750 ENSG00000275379 ENSG00000277775
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP68431
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SAM
Query on SAM
Download Ideal Coordinates CCD File
F [auth A]S-ADENOSYLMETHIONINE
C15 H22 N6 O5 S
MEFKEPWMEQBLKI-FCKMPRQPSA-N		 Ligand Interaction
ZN
Query on ZN
Download Ideal Coordinates CCD File
C [auth A],
D [auth A],
E [auth A]		ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N		 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.42 Å
  • R-Value Free: 0.269
  • R-Value Work: 0.204
  • R-Value Observed: 0.207
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 58.493α = 90
b = 76.316β = 90
c = 77.179γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


View more in-depth experimental data

Entry History & Funding Information

Deposition Data

  • Deposited Date: 2017-03-02
  • Released Date: 2017-03-22
    • Deposition Author(s): Zhang, Y., Tong, L.
Funding OrganizationLocationGrant Number
National Institutes of Health/Office of the DirectorUnited StatesS10-OD012018
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR01-GM085145

Revision History  (Full details and data files)

  • Version 1.0: 2017-03-22
    Type: Initial release
  • Version 1.1: 2017-03-29
    Changes: Database references
  • Version 1.2: 2017-09-27
    Changes: Author supporting evidence
  • Version 1.3: 2018-03-07
    Changes: Data collection
  • Version 1.4: 2020-01-01
    Changes: Author supporting evidence
