Biological Assembly 1

 3D View: Structure | Electron Density | Ligand Interaction

Standalone Viewers
Protein Workshop | Ligand Explorer

Global Symmetry: Dihedral - D2  (3D View)
Global Stoichiometry: Homo 4-mer - A4

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: homology

Macromolecule Content

• Total Structure Weight: 34042.74
• Atom Count: 2189
• Residue Count: 302
• Unique protein chains: 1

5V10

Crystal structure of the putative tol-pal system-associated acyl-CoA thioesterase from Pseudomonas aeruginosa PAO1

• DOI: 10.2210/pdb5V10/pdb

• Classification: STRUCTURAL GENOMICS UNKNOWN FUNCTION
• Organism(s): Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1)
• Expression System: Escherichia coli BL21(DE3)


• Deposited: 2017-02-28 Released: 2017-03-22
• Deposition Author(s): Borek, D., Wawrzak, Z., Grimshaw, S., Sandoval, J., Evdokimova, E., Savchenko, A., Anderson, W.F., Center for Structural Genomics of Infectious Diseases (CSGID)
• Funding Organization(s): National Institute of Allergy and Infectious Diseases, National Institutes of Health, Department of Health and Human Services

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.9 Å
• R-Value Free: 0.283
• R-Value Work: 0.220

Literature

Crystal structure of the putative tol-pal system-associated acyl-CoA thioesterase from Pseudomonas aeruginosa PAO1

Borek, D., Wawrzak, Z., Grimshaw, S., Sandoval, J., Evdokimova, E., Savchenko, A., Anderson, W.F., Center for Structural Genomics of Infectious Diseases (CSGID)

To be published.

Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details
Uncharacterized protein	A, B	151	Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1)	Mutation(s): 0
Find proteins for Q9I4Z5 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1)) Go to UniProtKB:  Q9I4Z5

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram & Interactions
CL	A, B	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.9 Å
• R-Value Free: 0.283
• R-Value Work: 0.220
• Space Group: C 1 2 1
• Diffraction Data DOI:
  10.18430/M35V10 Protein Diffraction

Unit Cell:

Length (Å)	Angle (°)
a = 97.994	α = 90.00
b = 62.279	β = 112.52
c = 52.792	γ = 90.00

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-3000	data reduction
HKL-3000	data scaling
MOLREP	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Deposited Date: 2017-02-28
• Released Date: 2017-03-22
• Deposition Author(s): Borek, D., Wawrzak, Z., Grimshaw, S., Sandoval, J., Evdokimova, E., Savchenko, A., Anderson, W.F., Center for Structural Genomics of Infectious Diseases (CSGID)

---

Funding Organization	Location	Grant Number
National Institute of Allergy and Infectious Diseases, National Institutes of Health, Department of Health and Human Services	United States	HHSN272200700058C
National Institute of Allergy and Infectious Diseases, National Institutes of Health, Department of Health and Human Services	United States	HHSN272201200026C

Revision History

• Version 1.0: 2017-03-22
  Type: Initial release
