5UVY | pdb_00005uvy

BRD4 Bromodomain 2 with A-1349391

PDB DOI: https://doi.org/10.2210/pdb5UVY/pdb

Classification: SIGNALING PROTEIN/INHIBITOR
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2017-02-20 Released: 2017-06-14
Deposition Author(s): Park, C.H.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.25 Å
R-Value Free:
0.262 (Depositor), 0.253 (DCC)
R-Value Work:
0.215 (Depositor), 0.216 (DCC)
R-Value Observed:
0.217 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 5UVY

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

BRD4 Bromodomain 2 with A-1349391

Park, C.H.

To be published.

Macromolecule Content

Total Structure Weight: 13.12 kDa
Atom Count: 1,000
Modeled Residue Count: 109
Deposited Residue Count: 109
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Bromodomain-containing protein 4	A	109	Homo sapiens	Mutation(s): 0 Gene Names: BRD4, HUNK1
UniProt & NIH Common Fund Data Resources
Find proteins for O60885 (Homo sapiens) Explore O60885 Go to UniProtKB: O60885
PHAROS: O60885 GTEx: ENSG00000141867
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	O60885
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
8NJ Query on 8NJ Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	6-methyl-4-(2-phenoxyphenyl)-1,6-dihydro-7H-pyrrolo[2,3-c]pyridin-7-one C₂₀ H₁₆ N₂ O₂ NUAFIMXCNWRSMX-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Binding Affinity Annotations
ID	Source	Binding Affinity
8NJ	BindingDB: 5UVY	Ki: 41 (nM) from 1 assay(s)

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.25 Å
R-Value Free: 0.262 (Depositor), 0.253 (DCC)
R-Value Work: 0.215 (Depositor), 0.216 (DCC)
R-Value Observed: 0.217 (Depositor)

Space Group: P 2₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 58.114	α = 90
b = 73.011	β = 90
c = 33.499	γ = 90

Software Package:

Software Name	Purpose
XDS	data reduction
SCALA	data scaling
Coot	model building
BUSTER	refinement

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2017-06-14

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2017-06-14
Type: Initial release
Version 1.1: 2024-03-06
Changes: Data collection, Database references
