5UUS | pdb_00005uus

SrtF sortase from Corynebacterium diphtheriae

PDB DOI: https://doi.org/10.2210/pdb5UUS/pdb

Classification: HYDROLASE
Organism(s): Corynebacterium diphtheriae NCTC 13129
Expression System: Escherichia coli 'BL21-Gold(DE3)pLysS AG
Mutation(s): No

Deposited: 2017-02-17 Released: 2017-03-22
Deposition Author(s): Osipiuk, J., Gornicki, P., Ton-That, H., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.02 Å
R-Value Free:
0.191 (Depositor), 0.190 (DCC)
R-Value Work:
0.164 (Depositor), 0.170 (DCC)
R-Value Observed:
0.165 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.5 of the entry. See complete history.

Literature

SrtF sortase from Corynebacterium diphtheriae

Osipiuk, J., Gornicki, P., Ton-That, H., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

To be published.

Macromolecule Content

Total Structure Weight: 50.99 kDa
Atom Count: 3,387
Modeled Residue Count: 413
Deposited Residue Count: 458
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Possible sortase-like protein	A, B	229	Corynebacterium diphtheriae NCTC 13129	Mutation(s): 0 Gene Names: DIP2272
UniProt
Find proteins for Q6NEK1 (Corynebacterium diphtheriae (strain ATCC 700971 / NCTC 13129 / Biotype gravis)) Explore Q6NEK1 Go to UniProtKB: Q6NEK1
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q6NEK1
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 5 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
MPD Query on MPD Download Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain D [auth A] SDF format, chain I [auth B] SDF format, chain J [auth B] MOL2 format, chain C [auth A] MOL2 format, chain D [auth A] MOL2 format, chain I [auth B] MOL2 format, chain J [auth B] mmCIF format, chain C [auth A] mmCIF format, chain D [auth A] mmCIF format, chain I [auth B] mmCIF format, chain J [auth B]	C [auth A], D [auth A], I [auth B], J [auth B]	(4S)-2-METHYL-2,4-PENTANEDIOL C₆ H₁₄ O₂ SVTBMSDMJJWYQN-YFKPBYRVSA-N		Interactions Focus chain C [auth A] Focus chain D [auth A] Focus chain I [auth B] Focus chain J [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth A] Focus chain I [auth B] Focus chain J [auth B]
EDO Query on EDO Download Ideal Coordinates CCD File SDF format, chain G [auth A] SDF format, chain M [auth B] MOL2 format, chain G [auth A] MOL2 format, chain M [auth B] mmCIF format, chain G [auth A] mmCIF format, chain M [auth B]	G [auth A], M [auth B]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain G [auth A] Focus chain M [auth B] Interactions & Density Focus chain G [auth A] Focus chain M [auth B]
ACT Query on ACT Download Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain L [auth B] MOL2 format, chain F [auth A] MOL2 format, chain L [auth B] mmCIF format, chain F [auth A] mmCIF format, chain L [auth B]	F [auth A], L [auth B]	ACETATE ION C₂ H₃ O₂ QTBSBXVTEAMEQO-UHFFFAOYSA-M		Interactions Focus chain F [auth A] Focus chain L [auth B] Interactions & Density Focus chain F [auth A] Focus chain L [auth B]
FMT Query on FMT Download Ideal Coordinates CCD File SDF format, chain H [auth A] MOL2 format, chain H [auth A] mmCIF format, chain H [auth A]	H [auth A]	FORMIC ACID C H₂ O₂ BDAGIHXWWSANSR-UHFFFAOYSA-N		Interactions Focus chain H [auth A] Interactions & Density Focus chain H [auth A]
CL Query on CL Download Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain K [auth B] MOL2 format, chain E [auth A] MOL2 format, chain K [auth B] mmCIF format, chain E [auth A] mmCIF format, chain K [auth B]	E [auth A], K [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain E [auth A] Focus chain K [auth B] Interactions & Density Focus chain E [auth A] Focus chain K [auth B]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
CSO Query on CSO	A, B	L-PEPTIDE LINKING	C₃ H₇ N O₃ S		CYS

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.02 Å
R-Value Free: 0.191 (Depositor), 0.190 (DCC)
R-Value Work: 0.164 (Depositor), 0.170 (DCC)
R-Value Observed: 0.165 (Depositor)

Diffraction Data: https://doi.org/10.18430/m35uus

Space Group: P 3₂ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 69.99	α = 90
b = 69.99	β = 90
c = 237.292	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
PDB_EXTRACT	data extraction
HKL-3000	data scaling
HKL-3000	data reduction
HKL-3000	phasing
DENZO	data reduction
SCALEPACK	data scaling

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2017-03-22

Deposition Author(s):

Center for Structural Genomics of Infectious Diseases (CSGID)

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	HHSN272200700058C
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	HHSN272201200026C

Revision History (Full details and data files)

Version 1.0: 2017-03-22
Type: Initial release
Version 1.1: 2017-09-27
Changes: Author supporting evidence, Refinement description
Version 1.2: 2019-12-11
Changes: Author supporting evidence
Version 1.3: 2023-10-04
Changes: Data collection, Database references, Refinement description
Version 1.4: 2023-11-15
Changes: Data collection
Version 1.5: 2024-10-09
Changes: Structure summary
