5UQX

USP7 in complex with GNE6776 (6'-amino-4'-ethyl-5'-(4-hydroxyphenyl)-N-methyl-[3,3'-bipyridine]-6-carboxamide)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.23 Å
  • R-Value Free: 0.223
  • R-Value Work: 0.188
  • R-Value Observed: 0.190

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history


Literature

USP7 small-molecule inhibitors interfere with ubiquitin binding.

Kategaya, L.Di Lello, P.Rouge, L.Pastor, R.Clark, K.R.Drummond, J.Kleinheinz, T.Lin, E.Upton, J.P.Prakash, S.Heideker, J.McCleland, M.Ritorto, M.S.Alessi, D.R.Trost, M.Bainbridge, T.W.Kwok, M.C.M.Ma, T.P.Stiffler, Z.Brasher, B.Tang, Y.Jaishankar, P.Hearn, B.R.Renslo, A.R.Arkin, M.R.Cohen, F.Yu, K.Peale, F.Gnad, F.Chang, M.T.Klijn, C.Blackwood, E.Martin, S.E.Forrest, W.F.Ernst, J.A.Ndubaku, C.Wang, X.Beresini, M.H.Tsui, V.Schwerdtfeger, C.Blake, R.A.Murray, J.Maurer, T.Wertz, I.E.

(2017) Nature 550: 534-538

  • DOI: https://doi.org/10.1038/nature24006
  • Primary Citation of Related Structures:
    5UQV, 5UQX

  • PubMed Abstract:

    The ubiquitin system regulates essential cellular processes in eukaryotes. Ubiquitin is ligated to substrate proteins as monomers or chains and the topology of ubiquitin modifications regulates substrate interactions with specific proteins. Thus ubiquitination directs a variety of substrate fates including proteasomal degradation. Deubiquitinase enzymes cleave ubiquitin from substrates and are implicated in disease; for example, ubiquitin-specific protease-7 (USP7) regulates stability of the p53 tumour suppressor and other proteins critical for tumour cell survival. However, developing selective deubiquitinase inhibitors has been challenging and no co-crystal structures have been solved with small-molecule inhibitors. Here, using nuclear magnetic resonance-based screening and structure-based design, we describe the development of selective USP7 inhibitors GNE-6640 and GNE-6776. These compounds induce tumour cell death and enhance cytotoxicity with chemotherapeutic agents and targeted compounds, including PIM kinase inhibitors. Structural studies reveal that GNE-6640 and GNE-6776 non-covalently target USP7 12 Å distant from the catalytic cysteine. The compounds attenuate ubiquitin binding and thus inhibit USP7 deubiquitinase activity. GNE-6640 and GNE-6776 interact with acidic residues that mediate hydrogen-bond interactions with the ubiquitin Lys48 side chain, suggesting that USP7 preferentially interacts with and cleaves ubiquitin moieties that have free Lys48 side chains. We investigated this idea by engineering di-ubiquitin chains containing differential proximal and distal isotopic labels and measuring USP7 binding by nuclear magnetic resonance. This preferential binding protracted the depolymerization kinetics of Lys48-linked ubiquitin chains relative to Lys63-linked chains. In summary, engineering compounds that inhibit USP7 activity by attenuating ubiquitin binding suggests opportunities for developing other deubiquitinase inhibitors and may be a strategy more broadly applicable to inhibiting proteins that require ubiquitin binding for full functional activity.


  • Organizational Affiliation

    Department of Discovery Oncology, Genentech, South San Francisco, California 94080, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Ubiquitin carboxyl-terminal hydrolase 7
A, B
369Homo sapiensMutation(s): 0
Gene Names: USP7HAUSP
EC: 3.4.19.12
UniProt & NIH Common Fund Data Resources
Find proteins for Q93009 (Homo sapiens)
Explore Q93009
Go to UniProtKB:  Q93009
PHAROS:  Q93009
GTEx:  ENSG00000187555
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ93009
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
8JP
Query on 8JP

Download Ideal Coordinates CCD File
C [auth A],
D [auth B]
6'-amino-4'-ethyl-5'-(4-hydroxyphenyl)-N-methyl[3,3'-bipyridine]-6-carboxamide
C20 H20 N4 O2
UCYSSYGGXOFJKK-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.23 Å
  • R-Value Free: 0.223
  • R-Value Work: 0.188
  • R-Value Observed: 0.190
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 76.355α = 90
b = 67.533β = 96.99
c = 76.861γ = 90
Software Package:
Software NamePurpose
SCALAdata scaling
PHENIXrefinement
PDB_EXTRACTdata extraction
XDSdata reduction

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2017-10-25
    Type: Initial release
  • Version 1.1: 2017-11-08
    Changes: Database references
  • Version 1.2: 2017-11-15
    Changes: Data collection
  • Version 1.3: 2023-10-04
    Changes: Data collection, Database references, Refinement description
