5UPZ

HIV-1 wild Type protease with GRL-0518A , an isophthalamide-derived P2-P3 ligand with the para-hydoxymethyl sulfonamide isostere as the P2' group

  • Classification: hydrolase/hydrolase inhibitor
  • Organism(s): Human immunodeficiency virus 1
  • Expression System: Escherichia coli BL21(DE3)
  • Mutation(s): Yes

  • Deposited: 2017-02-05 Released: 2017-05-10
  • Deposition Author(s): Wang, Y.-F., Agniswamy, J., Weber, I.T.
  • Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS), Department of Energy (DOE, United States), National Institutes of Health/National Cancer Institute (NIH/NCI), Ministry of Education, Culture, Sports, Science and Technology (Japan), he Ministry of Health, Welfare, and Labor, Purdue University

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.27 Å
  • R-Value Free: 0.198
  • R-Value Work: 0.144

wwPDB Validation 3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Design of novel HIV-1 protease inhibitors incorporating isophthalamide-derived P2-P3 ligands: Synthesis, biological evaluation and X-ray structural studies of inhibitor-HIV-1 protease complex.

Ghosh, A.K.Brindisi, M.Nyalapatla, P.R.Takayama, J.Ella-Menye, J.R.Yashchuk, S.Agniswamy, J.Wang, Y.F.Aoki, M.Amano, M.Weber, I.T.Mitsuya, H.

(2017) Bioorg Med Chem 25: 5114-5127

  • DOI: 10.1016/j.bmc.2017.04.005
  • Structures With Same Primary Citation

  • PubMed Abstract:
  • Based upon molecular insights from the X-ray structures of inhibitor-bound HIV-1 protease complexes, we have designed a series of isophthalamide-derived inhibitors incorporating substituted pyrrolidines, piperidines and thiazolidines as P2-P3 ligands ...

    Based upon molecular insights from the X-ray structures of inhibitor-bound HIV-1 protease complexes, we have designed a series of isophthalamide-derived inhibitors incorporating substituted pyrrolidines, piperidines and thiazolidines as P2-P3 ligands for specific interactions in the S2-S3 extended site. Compound 4b has shown an enzyme K i of 0.025nM and antiviral IC 50 of 69nM. An X-ray crystal structure of inhibitor 4b-HIV-1 protease complex was determined at 1.33Å resolution. We have also determined X-ray structure of 3b-bound HIV-1 protease at 1.27Å resolution. These structures revealed important molecular insight into the inhibitor-HIV-1 protease interactions in the active site.


    Organizational Affiliation

    Department of Hematology, Kumamoto University of Medicine, Kumamoto 860-8556, Japan; Department of Infectious Diseases, Kumamoto University of Medicine, Kumamoto 860-8556, Japan; Experimental Retrovirology Section, HIV and AIDS Malignancy Branch National Cancer Institute, Bethesda, MD 20892, USA; Department of Refractory Viral Infection, National Center for Global Health and Medicine Research Institute, Shinjuku, Tokyo 162-8655, Japan.



Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Protease
A, B
99Human immunodeficiency virus 1Mutation(s): 5
Gene Names: pol
Find proteins for C8B467 (Human immunodeficiency virus 1)
Go to UniProtKB:  C8B467
Small Molecules
Ligands 4 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
8HD
Query on 8HD

Download CCD File
A
N~3~-{(2S,3R)-3-hydroxy-4-[{[4-(hydroxymethyl)phenyl]sulfonyl}(2-methylpropyl)amino]-1-phenylbutan-2-yl}-N~1~-methyl-N~1~-[(4-methyl-1,3-oxazol-2-yl)methyl]benzene-1,3-dicarboxamide
C35 H42 N4 O7 S
PQWSVCGBIGOYSI-AJQTZOPKSA-N
 Ligand Interaction
GOL
Query on GOL

Download CCD File
A, B
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
 Ligand Interaction
CL
Query on CL

Download CCD File
A, B
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
 Ligand Interaction
NA
Query on NA

Download CCD File
A, B
SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N
 Ligand Interaction
External Ligand Annotations
IDBinding Affinity (Sequence Identity %)
8HDKi:  0.6299999952316284   nM  Binding MOAD
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.27 Å
  • R-Value Free: 0.198
  • R-Value Work: 0.144
  • Space Group: P 21 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 58.175α = 90
b = 86.418β = 90
c = 45.828γ = 90
Software Package:
Software NamePurpose
HKL-2000data reduction
HKL-2000data scaling
AMoREphasing
SHELXL-97refinement

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM53386
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM62920
Department of Energy (DOE, United States)United StatesNo. W-31-109-Eng-38
National Institutes of Health/National Cancer Institute (NIH/NCI)United Statesthe Intramural Research Program of the Center for Cancer Research
Ministry of Education, Culture, Sports, Science and Technology (Japan)Japana Grant-in-Aid for Scientific Research (Priority Areas)
he Ministry of Health, Welfare, and LaborJapana Grant for Promotion of AIDS Research
Ministry of Education, Culture, Sports, Science and Technology (Japan)Japanthe Grant to the Cooperative Research Project on Clinical and Epidemiological Studies of Emerging and Reemerging Infectious Diseases (Renkei Jigyo)
Purdue UniversityUnited Statesthe Purdue University Center for Cancer Research

Revision History

  • Version 1.0: 2017-05-10
    Type: Initial release
  • Version 1.1: 2017-09-27
    Changes: Author supporting evidence
  • Version 1.2: 2017-10-04
    Changes: Database references
  • Version 1.3: 2019-12-04
    Changes: Author supporting evidence
