Structure of amyloid-beta derived peptide - NKGAIF

Experimental Data Snapshot

  • Resolution: 1.45 Å
  • R-Value Free: 0.191
  • R-Value Work: 0.174
  • R-Value Observed: 0.176

wwPDB Validation   3D Report Full Report

This is version 1.1 of the entry. See complete history


Distal amyloid beta-protein fragments template amyloid assembly.

Do, T.D.Sangwan, S.de Almeida, N.E.C.Ilitchev, A.I.Giammona, M.Sawaya, M.R.Buratto, S.K.Eisenberg, D.S.Bowers, M.T.

(2018) Protein Sci 27: 1181-1190

  • DOI: https://doi.org/10.1002/pro.3375
  • Primary Citation of Related Structures:
    5TXD, 5TXH, 5TXJ

  • PubMed Abstract:

    Amyloid formation is associated with devastating diseases such as Alzheimer's, Parkinson's and Type-2 diabetes. The large amyloid deposits found in patients suffering from these diseases have remained difficult to probe by structural means. Recent NMR models also predict heterotypic interactions from distinct peptide fragments but limited evidence of heterotypic packed sheets is observed in solution. Here we characterize two segments of the protein amyloid β (Aβ) known to form fibrils in Alzheimer's disease patients. We designed two variants of Aβ(19-24) and Aβ(27-32), IFAEDV (I6V) and NKGAIF (N6F) to lower the aggregation propensity of individual peptides while maintaining the similar interactions between the two segments in their native forms. We found that the variants do not form significant amyloid fibrils individually but a 1:1 mixture forms abundant fibrils. Using ion mobility-mass spectrometry (IM-MS), hetero-oligomers up to decamers were found in the mixture while the individual peptides formed primarily dimers and some tetramers consistent with a strong heterotypic interaction between the two segments. We showed by X-ray crystallography that I6V formed a Class 7 zipper with a weakly packed pair of β-sheets and no segregated dry interface, while N6F formed a more stable Class 1 zipper. In a mixture of equimolar N6F:I6V, I6V forms a more stable zipper than in I6V alone while no N6F or hetero-typic zippers are observed. These data are consistent with a mechanism where N6F catalyzes assembly of I6V into a stable zipper and perhaps into stable, pure I6V fibrils that are observed in AFM measurements.

  • Organizational Affiliation

    Department of Chemistry and Biochemistry, University of California, Santa Barbara, California.


Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Amyloid beta A4 proteinA [auth Z]6Homo sapiensMutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for P05067 (Homo sapiens)
Explore P05067
Go to UniProtKB:  P05067
GTEx:  ENSG00000142192
Entity Groups
UniProt GroupP05067
Sequence Annotations
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
Query on PO4

Download Ideal Coordinates CCD File
O4 P
Experimental Data & Validation

Experimental Data

  • Resolution: 1.45 Å
  • R-Value Free: 0.191
  • R-Value Work: 0.174
  • R-Value Observed: 0.176
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 29.402α = 90
b = 4.827β = 102.04
c = 26.612γ = 90
Software Package:
Software NamePurpose
PDB_EXTRACTdata extraction
XDSdata reduction
XSCALEdata scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2017-11-15
    Type: Initial release
  • Version 1.1: 2018-10-10
    Changes: Data collection, Database references, Structure summary
