5TVK | pdb_00005tvk

Crystal Structure of putative plasmid partition protein (BB_S35) from Borrelia burgdorferi B31 bound to AMPPNP

• PDB DOI: https://doi.org/10.2210/pdb5TVK/pdb

• Classification: CELL CYCLE
• Organism(s): Borreliella burgdorferi B31
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2016-11-09 Released: 2016-11-23
• Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease (SSGCID)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.40 Å
• R-Value Free:
  0.218 (Depositor), 0.220 (DCC)
• R-Value Work:
  0.169 (Depositor), 0.170 (DCC)
• R-Value Observed:
  0.173 (Depositor)

Starting Model: experimental

Literature

Crystal Structure of putative plasmid partition protein (BB_S35) from Borrelia burgdorferi B31 bound to AMPPNP

SSGCID, Delker, S.L., Yano, J.K., Lorimer, D., Edwards, T.E.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 63 kDa
• Atom Count: 3,896
• Modeled Residue Count: 479
• Deposited Residue Count: 534
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
PF-32 protein	A, B	267	Borreliella burgdorferi B31	Mutation(s): 0  Gene Names: BB_S35, PF-32
UniProt
Find proteins for H7C7Q1 (Borreliella burgdorferi (strain ATCC 35210 / DSM 4680 / CIP 102532 / B31)) Explore H7C7Q1  Go to UniProtKB:  H7C7Q1

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
ANP	C [auth A], F [auth B]	PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER C10 H17 N6 O12 P3 PVKSNHVPLWYQGJ-KQYNXXCUSA-N
LI	D [auth A], E [auth A]	LITHIUM ION Li HBBGRARXTFLTSG-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.40 Å
• R-Value Free:  0.218 (Depositor), 0.220 (DCC)
• R-Value Work:  0.169 (Depositor), 0.170 (DCC)
• R-Value Observed: 0.173 (Depositor)

Space Group: P 6₅

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 57.32	α = 90
b = 57.32	β = 90
c = 343.57	γ = 120

Software Package:

Software Name	Purpose
XSCALE	data scaling
PHENIX	refinement
PDB_EXTRACT	data extraction
XDS	data reduction
MoRDa	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2016-11-23
Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Revision History

• Version 1.0: 2016-11-23
  Type: Initial release

• Version 1.1: 2023-10-04
  Changes: Data collection, Database references, Refinement description
