5TJF

The crystal structure of Allophycocyanin from the red algae Gracilaria chilensis


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.3 Å
  • R-Value Free: 0.284
  • R-Value Work: 0.257

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Structural models of the different trimers present in the core of phycobilisomes from Gracilaria chilensis based on crystal structures and sequences.

Dagnino-Leone, J.Figueroa, M.Mella, C.Vorphal, M.A.Kerff, F.Vasquez, A.J.Bunster, M.Martinez-Oyanedel, J.

(2017) PLoS ONE 12: e0177540-e0177540

  • DOI: 10.1371/journal.pone.0177540

  • PubMed Abstract:
  • Phycobilisomes (PBS) are accessory light harvesting protein complexes that directionally transfer energy towards photosystems. Phycobilisomes are organized in a central core and rods radiating from it. Components of phycobilisomes in Gracilaria chile ...

    Phycobilisomes (PBS) are accessory light harvesting protein complexes that directionally transfer energy towards photosystems. Phycobilisomes are organized in a central core and rods radiating from it. Components of phycobilisomes in Gracilaria chilensis (Gch) are Phycobiliproteins (PBPs), Phycoerythrin (PE), and Phycocyanin (PC) in the rods, while Allophycocyanin (APC) is found in the core, and linker proteins (L). The function of such complexes depends on the structure of each component and their interaction. The core of PBS from cyanobacteria is mainly composed by cylinders of trimers of α and β subunits forming heterodimers of Allophycocyanin, and other components of the core including subunits αII and β18. As for the linkers, Linker core (LC) and Linker core membrane (LCM) are essential for the final emission towards photoreaction centers. Since we have previously focused our studies on the rods of the PBS, in the present article we investigated the components of the core in the phycobilisome from the eukaryotic algae, Gracilaria chilensis and their organization into trimers. Transmission electron microscopy provided the information for a three cylinders core, while the three dimensional structure of Allophycocyanin purified from Gch was determined by X-ray diffraction method and the biological unit was determined as a trimer by size exclusion chromatography. The protein sequences of all the components of the core were obtained by sequencing the corresponding genes and their expression confirmed by transcriptomic analysis. These subunits have seldom been reported in red algae, but not in Gracilaria chilensis. The subunits not present in the crystallographic structure were modeled to build the different composition of trimers. This article proposes structural models for the different types of trimers present in the core of phycobilisomes of Gch as a first step towards the final model for energy transfer in this system.


    Organizational Affiliation

    Departamento de Bioquímica y Biología Molecular, Facultad de Ciencias Biológicas, Universidad de Concepción, Concepción, Chile.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Allophycocyanin alpha subunit
A
160Gracilaria chilensisMutation(s): 0
Gene Names: apcA
Find proteins for A0A141SEH2 (Gracilaria chilensis)
Go to UniProtKB:  A0A141SEH2
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
Allophycocyanin beta subunit
B
161Gracilaria chilensisMutation(s): 0
Gene Names: apcB
Find proteins for A0A141SEH3 (Gracilaria chilensis)
Go to UniProtKB:  A0A141SEH3
Small Molecules
Ligands 4 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
NA
Query on NA

Download SDF File
Download CCD File
A, B
SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N
 Ligand Interaction
CL
Query on CL

Download SDF File
Download CCD File
A, B
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
 Ligand Interaction
CYC
Query on CYC

Download SDF File
Download CCD File
A, B
PHYCOCYANOBILIN
C33 H40 N4 O6
VXTXPYZGDQPMHK-GMXXPEQVSA-N
 Ligand Interaction
PEG
Query on PEG

Download SDF File
Download CCD File
A, B
DI(HYDROXYETHYL)ETHER
C4 H10 O3
MTHSVFCYNBDYFN-UHFFFAOYSA-N
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
MEN
Query on MEN
B
L-PEPTIDE LINKINGC5 H10 N2 O3ASN
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.3 Å
  • R-Value Free: 0.284
  • R-Value Work: 0.257
  • Space Group: P 3 2 1
Unit Cell:
Length (Å)Angle (°)
a = 97.410α = 90.00
b = 97.410β = 90.00
c = 63.830γ = 120.00
Software Package:
Software NamePurpose
XDSdata reduction
XDSdata scaling
PHENIXrefinement
PHASERphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
CONICYTChileFONDECYT 113.0256

Revision History

  • Version 1.0: 2017-05-24
    Type: Initial release
  • Version 1.1: 2017-06-07
    Type: Database references, Derived calculations, Structure summary
