5T0S

Synaptotagmin 1 C2B domain, cadmium-bound


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.42 Å
  • R-Value Free: 0.198
  • R-Value Work: 0.159

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Non-Native Metal Ion Reveals the Role of Electrostatics in Synaptotagmin 1-Membrane Interactions.

Katti, S.Nyenhuis, S.B.Her, B.Srivastava, A.K.Taylor, A.B.Hart, P.J.Cafiso, D.S.Igumenova, T.I.

(2017) Biochemistry 56: 3283-3295

  • DOI: 10.1021/acs.biochem.7b00188
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • C2 domains are independently folded modules that often target their host proteins to anionic membranes in a Ca2+-dependent manner. In these cases, membrane association is triggered by Ca2+ binding to the negatively charged loop region of the C2 domai ...

    C2 domains are independently folded modules that often target their host proteins to anionic membranes in a Ca2+-dependent manner. In these cases, membrane association is triggered by Ca2+ binding to the negatively charged loop region of the C2 domain. Here, we used a non-native metal ion, Cd2+, in lieu of Ca2+ to gain insight into the contributions made by long-range Coulombic interactions and direct metal ion-lipid bridging to membrane binding. Using X-ray crystallography, NMR, Förster resonance energy transfer, and vesicle cosedimentation assays, we demonstrate that, although Cd2+ binds to the loop region of C2A/B domains of synaptotagmin 1 with high affinity, long-range Coulombic interactions are too weak to support membrane binding of individual domains. We attribute this behavior to two factors: the stoichiometry of Cd2+ binding to the loop regions of the C2A and C2B domains and the impaired ability of Cd2+ to directly coordinate the lipids. In contrast, electron paramagnetic resonance experiments revealed that Cd2+ does support membrane binding of the C2 domains in full-length synaptotagmin 1, where the high local lipid concentrations that result from membrane tethering can partially compensate for lack of a full complement of divalent metal ions and specific lipid coordination in Cd2+-complexed C2A/B domains. Our data suggest that long-range Coulombic interactions alone can drive the initial association of C2A/B with anionic membranes and that Ca2+ further augments membrane binding by the formation of metal ion-lipid coordination bonds and additional Ca2+ ion binding to the C2 domain loop regions.


    Organizational Affiliation

    Department of Biochemistry and Biophysics, Texas A&M University , 300 Olsen Boulevard, College Station, Texas 77843, United States.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Synaptotagmin-1
A
151Mus musculusMutation(s): 0
Gene Names: Syt1
Find proteins for P46096 (Mus musculus)
Go to UniProtKB:  P46096
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
NA
Query on NA

Download SDF File
Download CCD File
A
SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N
 Ligand Interaction
CD
Query on CD

Download SDF File
Download CCD File
A
CADMIUM ION
Cd
WLZRMCYVCSSEQC-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.42 Å
  • R-Value Free: 0.198
  • R-Value Work: 0.159
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 40.992α = 90.00
b = 41.948β = 90.00
c = 80.657γ = 90.00
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XDSdata scaling
PHASERphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2017-06-14
    Type: Initial release
  • Version 1.1: 2017-07-05
    Type: Database references
