5SB0

DDR1, N-[[2-(2-pyridin-3-yloxyethyl)cyclohexyl]methyl]-3-(trifluoromethoxy)benzamide, 1.970A, P212121, Rfree=25.6%

• PDB DOI: https://doi.org/10.2210/pdb5SB0/pdb
• Deposition Group: G_1002213 ExploreG_1002213

• Classification: TRANSFERASE/TRANSFERASE INHIBITOR
• Organism(s): Homo sapiens
• Expression System: Spodoptera frugiperda
• Mutation(s): No


• Deposited: 2021-06-22 Released: 2022-06-29
• Deposition Author(s): Stihle, M., Richter, H., Benz, J., Hochstrasser, R., Rudolph, M.G.
• Funding Organization(s): F. Hoffmann-La Roche

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.97 Å
• R-Value Free: 0.256
• R-Value Work: 0.208
• R-Value Observed: 0.210

Literature

Crystal Structure of a DDR1 complex

Richter, H., Prunotto, M., Kuhn, B., Rudolph, M.G.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 37.09 kDa
• Atom Count: 2,434
• Modelled Residue Count: 284
• Deposited Residue Count: 321
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Epithelial discoidin domain-containing receptor 1	A	321	Homo sapiens	Mutation(s): 0  Gene Names: DDR1, CAK, EDDR1, NEP, NTRK4, PTK3A, RTK6, TRKE EC: 2.7.10.1
UniProt & NIH Common Fund Data Resources
Find proteins for Q08345 (Homo sapiens) Explore Q08345  Go to UniProtKB:  Q08345
PHAROS:  Q08345 GTEx:  ENSG00000204580

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
1IZ (Subject of Investigation/LOI)	C [auth A]	N-{[(1R,2S)-2-{2-[(pyridin-3-yl)oxy]ethyl}cyclohexyl]methyl}-3-(trifluoromethoxy)benzamide C22 H25 F3 N2 O3 IERBKCIYEFEAOR-WMZOPIPTSA-N
IOD	B [auth A]	IODIDE ION I XMBWDFGMSWQBCA-UHFFFAOYSA-M
CL	D [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.97 Å
• R-Value Free: 0.256
• R-Value Work: 0.208
• R-Value Observed: 0.210
• Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 62.056	α = 90
b = 76.661	β = 90
c = 77.783	γ = 90

Software Package:

Software Name	Purpose
XSCALE	data scaling
PHENIX	refinement
PDB_EXTRACT	data extraction
XDS	data reduction
XSCALE	data scaling
PHASER	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2022-06-29
Deposition Author(s): Stihle, M., Richter, H., Benz, J., Hochstrasser, R., Rudolph, M.G.

---

Funding Organization	Location	Grant Number
F. Hoffmann-La Roche	Switzerland	--

Revision History

• Version 1.0: 2022-06-29
  Type: Initial release

• Version 1.1: 2024-04-03
  Changes: Data collection, Refinement description
