5QBK | pdb_00005qbk

Crystal structure of Endothiapepsin-NAT17-347144 complex

PDB DOI: https://doi.org/10.2210/pdb5QBK/pdb
Deposition Group: G_1002039 | Explore G_1002039

Classification: HYDROLASE
Organism(s): Cryphonectria parasitica
Mutation(s): No

Deposited: 2017-08-04 Released: 2020-04-22
Deposition Author(s): Huschmann, F.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.28 Å
R-Value Free:
0.179 (Depositor), 0.186 (DCC)
R-Value Work:
0.147 (Depositor)
R-Value Observed:
0.148 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 5QBK

Ligand Structure Quality Assessment

This is version 1.2 of the entry. See complete history.

Literature

Crystal structure of Endothiapepsin

Huschmann, F.U., Weiss, M.S., Mueller, U., Haustedt, L.O., Klebe, G.

To be published.

Macromolecule Content

Total Structure Weight: 34.71 kDa
Atom Count: 2,960
Modeled Residue Count: 330
Deposited Residue Count: 330
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Endothiapepsin	A	330	Cryphonectria parasitica	Mutation(s): 0 EC: 3.4.23.22
UniProt
Find proteins for P11838 (Cryphonectria parasitica) Explore P11838 Go to UniProtKB: P11838
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P11838
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
D97 Query on D97 Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A]	D [auth A], E [auth A]	(1S,2S,3S,4R,5R)-4-(morpholin-4-yl)-2-[(quinolin-3-ylmethyl)amino]-6,8-dioxabicyclo[3.2.1]octan-3-ol C₂₀ H₂₅ N₃ O₄ BOMGHVJKULNWEW-LTFPLMDUSA-N		Interactions Focus chain D [auth A] Focus chain E [auth A] Interactions & Density Focus chain D [auth A] Focus chain E [auth A]
DMS Query on DMS Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain B [auth A] MOL2 format, chain C [auth A] MOL2 format, chain B [auth A] mmCIF format, chain C [auth A] mmCIF format, chain B [auth A]	B [auth A], C [auth A]	DIMETHYL SULFOXIDE C₂ H₆ O S IAZDPXIOMUYVGZ-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Focus chain C [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.28 Å
R-Value Free: 0.179 (Depositor), 0.186 (DCC)
R-Value Work: 0.147 (Depositor)
R-Value Observed: 0.148 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 45.448	α = 90
b = 73.991	β = 110.6
c = 53.717	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XSCALE	data scaling
PDB_EXTRACT	data extraction

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2020-04-22

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2020-04-22
Type: Initial release
Version 1.1: 2021-11-17
Changes: Database references, Structure summary
Version 1.2: 2024-10-16
Changes: Data collection, Structure summary
