5PZY

Human liver fructose-1,6-bisphosphatase 1 (fructose 1,6-bisphosphate 1-phosphatase, E.C.3.1.3.11) complexed with the allosteric inhibitor 1-(5-bromo-1,3-thiazol-2-yl)-3-(2-chlorophenyl)sulfonylurea


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.21 Å
  • R-Value Free: 0.228
  • R-Value Work: 0.173
  • R-Value Observed: 0.175

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.4 of the entry. See complete history


Literature

Human liver fructose-1,6-bisphosphatase 1 (fructose 1,6-bisphosphate 1-phosphatase, E.C.3.1.3.11) complexed with the allosteric inhibitor 1-(5-bromo-1,3-thiazol-2-yl)-3-(2-chlorophenyl)sulfonylurea

Ruf, A.Joseph, C.Alker, A.Banner, D.Tetaz, T.Benz, J.Kuhn, B.Rudolph, M.G.

To be published.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Fructose-1,6-bisphosphatase 1
A, B, C, D, E
A, B, C, D, E, F, G, H
338Homo sapiensMutation(s): 0
Gene Names: FBP1hCG_1640493
EC: 3.1.3.11
UniProt & NIH Common Fund Data Resources
Find proteins for P09467 (Homo sapiens)
Explore P09467
Go to UniProtKB:  P09467
PHAROS:  P09467
GTEx:  ENSG00000165140
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP09467
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
94V
Query on 94V

Download Ideal Coordinates CCD File
I [auth A]
J [auth B]
K [auth C]
L [auth D]
M [auth E]
I [auth A],
J [auth B],
K [auth C],
L [auth D],
M [auth E],
N [auth F],
O [auth G],
P [auth H]
N-[(5-bromo-1,3-thiazol-2-yl)carbamoyl]-2-chlorobenzene-1-sulfonamide
C10 H7 Br Cl N3 O3 S2
NFXDNHRCLVIUNW-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.21 Å
  • R-Value Free: 0.228
  • R-Value Work: 0.173
  • R-Value Observed: 0.175
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 66.214α = 90
b = 283.778β = 97.31
c = 83.368γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2019-01-09
    Type: Initial release
  • Version 1.1: 2019-01-16
    Changes: Data collection
  • Version 1.2: 2019-02-06
    Changes: Data collection, Database references, Structure summary
  • Version 1.3: 2021-02-10
    Changes: Structure summary
  • Version 1.4: 2024-03-06
    Changes: Data collection, Database references, Refinement description
