5ONY

As-isolated resting state copper nitrite reductase from Achromobacter xylosoxidans


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.60 Å
  • R-Value Free: 0.223
  • R-Value Work: 0.190
  • R-Value Observed: 0.191

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

An unprecedented dioxygen species revealed by serial femtosecond rotation crystallography in copper nitrite reductase.

Halsted, T.P.Yamashita, K.Hirata, K.Ago, H.Ueno, G.Tosha, T.Eady, R.R.Antonyuk, S.V.Yamamoto, M.Hasnain, S.S.

(2018) IUCrJ 5: 22-31

  • DOI: 10.1107/S2052252517016128
  • Structures With Same Primary Citation

  • PubMed Abstract:
  • Synchrotron-based X-ray structural studies of ligand-bound enzymes are powerful tools to further our understanding of reaction mechanisms. For redox enzymes, it is necessary to study both the oxidized and reduced active sites to fully elucidate the r ...

    Synchrotron-based X-ray structural studies of ligand-bound enzymes are powerful tools to further our understanding of reaction mechanisms. For redox enzymes, it is necessary to study both the oxidized and reduced active sites to fully elucidate the reaction, an objective that is complicated by potential X-ray photoreduction. In the presence of the substrate, this can be exploited to construct a structural movie of the events associated with catalysis. Using the newly developed approach of serial femtosecond rotation crystallography (SF-ROX), an X-ray damage-free structure of the as-isolated copper nitrite reductase (CuNiR) was visualized. The sub-10 fs X-ray pulse length from the SACLA X-ray free-electron laser allowed diffraction data to be collected to 1.6 Å resolution in a 'time-frozen' state. The extremely short duration of the X-ray pulses ensures the capture of data prior to the onset of radiation-induced changes, including radiolysis. Unexpectedly, an O 2 ligand was identified bound to the T2Cu in a brand-new binding mode for a diatomic ligand in CuNiRs. The observation of O 2 in a time-frozen structure of the as-isolated oxidized enzyme provides long-awaited clear-cut evidence for the mode of O 2 binding in CuNiRs. This provides an insight into how CuNiR from Alcaligenes xylosoxidans can function as an oxidase, reducing O 2 to H 2 O 2 , or as a superoxide dismutase (SOD) since it was shown to have ∼56% of the dismutase activity of the bovine SOD enzyme some two decades ago.


    Organizational Affiliation

    Molecular Biophysics Group, Institute of Integrative Biology, Faculty of Health and Life Sciences, University of Liverpool, Liverpool L69 7ZB, England.



Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Copper-containing nitrite reductase
A
335Achromobacter xylosoxidansMutation(s): 0
Gene Names: nirnirKERS451415_02178
EC: 1.7.2.1
Find proteins for O68601 (Alcaligenes xylosoxydans xylosoxydans)
Go to UniProtKB:  O68601
Small Molecules
Ligands 4 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
MES
Query on MES

Download CCD File
A
2-(N-MORPHOLINO)-ETHANESULFONIC ACID
C6 H13 N O4 S
SXGZJKUKBWWHRA-UHFFFAOYSA-N
 Ligand Interaction
PG4
Query on PG4

Download CCD File
A
TETRAETHYLENE GLYCOL
C8 H18 O5
UWHCKJMYHZGTIT-UHFFFAOYSA-N
 Ligand Interaction
ZN
Query on ZN

Download CCD File
A
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
 Ligand Interaction
CU
Query on CU

Download CCD File
A
COPPER (II) ION
Cu
JPVYNHNXODAKFH-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.60 Å
  • R-Value Free: 0.223
  • R-Value Work: 0.190
  • R-Value Observed: 0.191
  • Space Group: H 3
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 90.347α = 90
b = 90.347β = 90
c = 143.58γ = 120
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
Aimlessdata scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Biotechnology and Biological Sciences Research CouncilUnited KingdomBB/L006960/1

Revision History

  • Version 1.0: 2017-11-29
    Type: Initial release
  • Version 1.1: 2018-01-31
    Changes: Database references
  • Version 1.2: 2018-10-03
    Changes: Data collection
