5OGI

Complex of a binding protein and human adenovirus C 5 hexon

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free: 0.235
  • R-Value Work: 0.198
  • R-Value Observed: 0.200

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history.


Literature

Adenoviral vector with shield and adapter increases tumor specificity and escapes liver and immune control.

Schmid, M., Ernst, P., Honegger, A., Suomalainen, M., Zimmermann, M., Braun, L., Stauffer, S., Thom, C., Dreier, B., Eibauer, M., Kipar, A., Vogel, V., Greber, U.F., Medalia, O., Pluckthun, A.

(2018) Nat Commun 9: 450-450

  • DOI: 10.1038/s41467-017-02707-6
  • Primary Citation of Related Structures:
    5OGI, 6EQC

  • PubMed Abstract:

    • Most systemic viral gene therapies have been limited by sequestration and degradation of virions, innate and adaptive immunity, and silencing of therapeutic genes within the target cells. Here we engineer a high-affinity protein coat, shielding the most commonly used vector in clinical gene therapy, human adenovirus type 5 ...

    Most systemic viral gene therapies have been limited by sequestration and degradation of virions, innate and adaptive immunity, and silencing of therapeutic genes within the target cells. Here we engineer a high-affinity protein coat, shielding the most commonly used vector in clinical gene therapy, human adenovirus type 5. Using electron microscopy and crystallography we demonstrate a massive coverage of the virion surface through the hexon-shielding scFv fragment, trimerized to exploit the hexon symmetry and gain avidity. The shield reduces virion clearance in the liver. When the shielded particles are equipped with adaptor proteins, the virions deliver their payload genes into human cancer cells expressing HER2 or EGFR. The combination of shield and adapter also increases viral gene delivery to xenografted tumors in vivo, reduces liver off-targeting and immune neutralization. Our study highlights the power of protein engineering for viral vectors overcoming the challenges of local and systemic viral gene therapies.

    Organizational Affiliation:

    Department of Biochemistry, University of Zurich, Winterthurerstr, 190, 8057, Zurich, Switzerland. plueckthun@bioc.uzh.ch.



Macromolecules
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Hexon proteinA952Human adenovirus 5Mutation(s): 0
Gene Names: L3
UniProt
Find proteins for P04133 (Human adenovirus C serotype 5)
Explore P04133
Go to UniProtKB:  P04133
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP04133
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
scFv of 9C12 antibodyB254Mus musculusMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 4 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
MES
Query on MES
Download Ideal Coordinates CCD File
T [auth A],
U [auth A],
V [auth A],
W [auth A]		2-(N-MORPHOLINO)-ETHANESULFONIC ACID
C6 H13 N O4 S
SXGZJKUKBWWHRA-UHFFFAOYSA-N		 Ligand Interaction
SO4
Query on SO4
Download Ideal Coordinates CCD File
C [auth A],
D [auth A],
E [auth A],
F [auth A],
G [auth A],
C [auth A],
D [auth A],
E [auth A],
F [auth A],
G [auth A],
H [auth A],
I [auth A]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L		 Ligand Interaction
DIO
Query on DIO
Download Ideal Coordinates CCD File
J [auth A],
K [auth A],
L [auth A],
M [auth A],
N [auth A],
J [auth A],
K [auth A],
L [auth A],
M [auth A],
N [auth A],
O [auth A],
P [auth A],
Q [auth A],
R [auth A],
X [auth B]
1,4-DIETHYLENE DIOXIDE
C4 H8 O2
RYHBNJHYFVUHQT-UHFFFAOYSA-N		 Ligand Interaction
EDO
Query on EDO
Download Ideal Coordinates CCD File
S [auth A]1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N		 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free: 0.235
  • R-Value Work: 0.198
  • R-Value Observed: 0.200
  • Space Group: P 63
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 158.185α = 90
b = 158.185β = 90
c = 140.805γ = 120
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XDSdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



View more in-depth experimental data

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2018-02-07
    Type: Initial release
  • Version 1.1: 2018-02-14
    Changes: Database references
