5NWZ

FIBROBLAST GROWTH FACTOR RECEPTOR 4 KINASE DOMAIN (449-753) IN COMPLEX WITH IRREVERSIBLE LIGAND CGA159527

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.37 Å

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history.


Literature

Approaches to selective fibroblast growth factor receptor 4 inhibition through targeting the ATP-pocket middle-hinge region.

Fairhurst, R.A., Knoepfel, T., Leblanc, C., Buschmann, N., Gaul, C., Blank, J., Galuba, I., Trappe, J., Zou, C., Voshol, J., Genick, C., Brunet-Lefeuvre, P., Bitsch, F., Graus-Porta, D., Furet, P.

(2017) Medchemcomm 8: 1604-1613

  • DOI: 10.1039/c7md00213k
  • Primary Citation of Related Structures:
    5NUD, 5NWZ

  • PubMed Abstract:

    • A diverse range of selective FGFR4 inhibitor hit series were identified using unbiased screening approaches and by the modification of known kinase inhibitor scaffolds. In each case the origin of the selectivity was consistent with an interaction with a poorly conserved cysteine residue within the middle-hinge region of the kinase domain of FGFR4, at position 552 ...

    A diverse range of selective FGFR4 inhibitor hit series were identified using unbiased screening approaches and by the modification of known kinase inhibitor scaffolds. In each case the origin of the selectivity was consistent with an interaction with a poorly conserved cysteine residue within the middle-hinge region of the kinase domain of FGFR4, at position 552. Targeting this region identified a non-covalent diaminopyrimidine series differentiating by size, an irreversible-covalent inhibitor in which Cys552 undergoes an SNAr reaction with a 2-chloropyridine, and a reversible-covalent inhibitor series in which Cys552 forms a hemithioacetal adduct with a 2-formyl naphthalene. In addition, the introduction of an acrylamide into a known FGFR scaffold identified a pan-FGFR inhibitor which reacted with both Cys552 and a second poorly conserved cysteine on the P-loop of FGFR4 at position 477 which is present in all four FGFR family members.

    Organizational Affiliation:

    Novartis Institutes for BioMedical Research , CH-4002 Basel , Switzerland . Email: robin.fairhurst@novartis.com.



Macromolecules
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Fibroblast growth factor receptor 4A, B307Homo sapiensMutation(s): 0
Gene Names: FGFR4, JTK2, TKF
EC: 2.7.10.1
UniProt & NIH Common Fund Data Resources
Find proteins for P22455 (Homo sapiens)
Explore P22455
Go to UniProtKB:  P22455
PHAROS:  P22455
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP22455
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
9CT
Query on 9CT
Download Ideal Coordinates CCD File
C [auth A],
D [auth B]		~{N}-[3-[2-(3,5-dimethoxyphenyl)ethyl]-1~{H}-pyrazol-5-yl]-2-(propanoylamino)benzamide
C23 H26 N4 O4
KYCYQUFXRBXHGL-UHFFFAOYSA-N		 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.37 Å
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 47.398α = 90
b = 75.958β = 90
c = 181.052γ = 90
Software Package:
Software NamePurpose
XDSdata reduction
XSCALEdata scaling
PHASERphasing
BUSTERrefinement

Structure Validation

View Full Validation Report



View more in-depth experimental data

Entry History

Deposition Data

  • Deposited Date: 2017-05-09
  • Released Date: 2018-04-04
    • Deposition Author(s): Zou, C.

Revision History  (Full details and data files)

  • Version 1.0: 2018-04-04
    Type: Initial release
  • Version 1.1: 2018-08-29
    Changes: Data collection, Database references
