5NV1 | pdb_00005nv1

SH3 domain from Mouse cortactin (C 2 2 21 crystal form)

• PDB DOI: https://doi.org/10.2210/pdb5NV1/pdb

• Classification: SIGNALING PROTEIN
• Organism(s): Mus musculus
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2017-05-03 Released: 2018-08-15
• Deposition Author(s): Twafra, S., Dessau, M.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.51 Å
• R-Value Work:
  0.230 (DCC)

Starting Model: experimental

Literature

SH3 domain from Mouse cortactin (C 2 2 21 crystal form)

Twafra, S., Gil-Henn, H., Dessau, M.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration, light scattering

Macromolecule Content

• Total Structure Weight: 7.11 kDa
• Atom Count: 570
• Modeled Residue Count: 60
• Deposited Residue Count: 60
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Src substrate cortactin	A	60	Mus musculus	Mutation(s): 0  Gene Names: Cttn, Ems1
UniProt & NIH Common Fund Data Resources
Find proteins for Q60598 (Mus musculus) Explore Q60598  Go to UniProtKB:  Q60598
IMPC:  MGI:99695

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
MES	B [auth A]	2-(N-MORPHOLINO)-ETHANESULFONIC ACID C6 H13 N O4 S SXGZJKUKBWWHRA-UHFFFAOYSA-N
GOL	C [auth A]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N
MG	D [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.51 Å
• R-Value Work:  0.230 (DCC)

Space Group: C 2 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 41.36	α = 90
b = 55.95	β = 90
c = 50.2	γ = 90

Software Package:

Software Name	Purpose
SCALA	data scaling
PHENIX	refinement
PDB_EXTRACT	data extraction
XDS	data reduction
PHASER	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2018-08-15
Deposition Author(s): Twafra, S., Dessau, M.

Revision History

• Version 1.0: 2018-08-15
  Type: Initial release

• Version 1.1: 2024-01-17
  Changes: Data collection, Database references, Derived calculations, Refinement description
