5N9E

Crystal Structure of Drosophila DHX36 helicase in complex with TGGGGATTT


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.007 Å
  • R-Value Free: 0.257
  • R-Value Work: 0.182

wwPDB Validation

Currently 5N9E does not have a wwPDB validation report.


This is version 1.0 of the entry. See complete history

Literature

Structural and mechanistic insights into DHX36-mediated innate immunity and G-quadruplex unfolding

Chen, W.-F.Rety, S.Hai-Lei Guo, H.-L.Wu, W.-Q.Liu, N.-N.Liu, Q.-W.Dai, Y.-X.Xi, X.-G.

To be published.

Macromolecules

Find similar proteins by: Sequence  |  Structure


Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
CG9323, isoform A
A, B
944Drosophila melanogasterGene Names: Rhau (38E.15, Dmel\CG9323)
Find proteins for Q8SWT2 (Drosophila melanogaster)
Go to UniProtKB:  Q8SWT2
Entity ID: 2
MoleculeChainsLengthOrganism
DNA (5'-D(P*TP*GP*GP*GP*GP*AP*TP*TP*T)-3')C,D9Homo sapiens
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.007 Å
  • R-Value Free: 0.257
  • R-Value Work: 0.182
  • Space Group: C 1 2 1
Unit Cell:
Length (Å)Angle (°)
a = 304.472α = 90.00
b = 51.242β = 114.67
c = 164.522γ = 90.00
Software Package:
Software NamePurpose
XDSdata reduction
PHASERphasing
Aimlessdata scaling
PHENIXrefinement

Structure Validation

Currently 5N9E does not have a wwPDB validation report.



Entry History

Deposition Data

Revision History

  • Version 1.0: 2018-03-21
    Type: Initial release
